DCS-8630LH security camera Box IP security camera Indoor & outdoor
1920 x 1080 pixels Wall/Pole
Model DCS-8630LHEAN 790069453496
38 specifications
- ConnectivityWireless
- TypeIP security camera
- Weight237 g
- ColourWhite
- Form factorBox
- Camera pan controlYes
Overview
- Connectivity
- Wireless
- Type
- IP security camera
- Weight
- 237 g
- Colour
- White
- Form factor
- Box
- Camera pan control
- Yes
- Brand
- D-Link
- Category
- Security Camera
- Model
- DCS-8630LH
- Part number
- DCS-8630LH
- EAN / UPC
- 790069453496
- Also known as
- D-Link DCS-8630LH security camera Box IP security camera Indoor & outdoor 1920 x 1080 pixels Wall/Pole
Specifications
38 specifications in 14 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wireless |
| PTZ control | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Box |
| Mounting type | Wall/Pole |
| Product colour | White |
| LED indicators | Yes |
| International Protection (IP) code | IP65 |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Lens viewing angle, horizontal | 123.8° |
| Lens viewing angle, vertical | 65.4° |
| Lens viewing angle, diagonal | 150° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 2.7 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 7 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | H.264 |
| Frame rate | 30 fps |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11g, Wi-Fi 4 (802.11n) |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA3 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 8 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -25 - 45 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 126 mm |
| Depth | 84 mm |
| Height | 60 mm |
| Weight | 237 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
