2K QHD Outdoor Wi-Fi Camera
Model DCS-8620LHEAN 790069462498
69 specifications
- ConnectivityWired & Wireless
- TypeIP security camera
- Weight157 g
- ColourWhite
- Form factorCube
- Field of view (FOV) angle127°
Overview
- Connectivity
- Wired & Wireless
- Type
- IP security camera
- Weight
- 157 g
- Colour
- White
- Form factor
- Cube
- Field of view (FOV) angle
- 127°
- Brand
- D-Link
- Category
- Security Camera
- Model
- DCS-8620LH
- Part number
- DCS-8620LH
- EAN / UPC
- 790069462498
- Also known as
- D-Link 2K QHD Outdoor Wi-Fi Camera
Specifications
69 specifications in 18 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired & Wireless |
| Virtual assistant | Amazon Alexa & Google Assistant |
| Day/night mode | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Cube |
| Mounting type | Ceiling/Wall/Pole |
| Product colour | White |
| Protection features | Dust resistant, Rain proof |
| International Protection (IP) code | IP65 |
| Weatherproof | Yes |
Camera
| Specification | Value |
|---|---|
| Field of view (FOV) angle | 127° |
| Lens viewing angle, horizontal | 108° |
| Lens viewing angle, vertical | 58° |
| Lens viewing angle, diagonal | 127° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Minimum aperture number | 1.6 |
| Fixed focal length | 2.97 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 7 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.264, H.265 |
| Supported video modes | 1440p |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio system | 2-way |
| Audio formats supported | AAC-LC |
| Built-in microphone | Yes |
| Voice codecs | AAC |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Supported network protocols | IPv4, IPv6, DHCP/DHCPv6 Client, Bonjour (mDNS and DNS-SD), ONVIF Profile S/T, RTSP, SRTP, RTP, HTTPS |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Frequency band | 2.4/5 GHz |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Security
| Specification | Value |
|---|---|
| Built-in siren | Yes |
| Siren noise level | 90 dB |
| Intelligent Video Surveillance (IVS) system features | Human detection |
| Motion sensor | Yes |
| Security algorithms | TLS, WPA3 |
Power
| Specification | Value |
|---|---|
| Power source type | AC, DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 5 W |
| DC output voltage | 12 |
| DC output current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -25 - 45 °C |
| Storage temperature (T-T) | 20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
System requirements
| Specification | Value |
|---|---|
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 89.1 mm |
| Depth | 60 mm |
| Height | 63 mm |
| Weight | 157 g |
| Cable length | 4 m |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Sustainability compliance | Yes |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
Other features
| Specification | Value |
|---|---|
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth version | 5.0 |
