DCS-8610 IP security camera Indoor
2560 x 1440 pixels Desk
Model DCS-8610Part no. DCS-8610/EEAN 790069482700
67 specifications
- ConnectivityWired & Wireless
- TypeIP security camera
- Weight320 g
- ColourWhite
- Mounting typeDesk
- Lens viewing angle, horizontal102.5°
Overview
- Connectivity
- Wired & Wireless
- Type
- IP security camera
- Weight
- 320 g
- Colour
- White
- Mounting type
- Desk
- Lens viewing angle, horizontal
- 102.5°
- Brand
- D-Link
- Category
- Security Camera
- Model
- DCS-8610
- Part number
- DCS-8610/E
- EAN / UPC
- 790069482700
- Also known as
- D-Link DCS-8610 IP security camera Indoor 2560 x 1440 pixels Desk
Specifications
67 specifications in 18 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor |
| Connectivity technology | Wired & Wireless |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Certification | FCC Class B; CE |
Design
| Specification | Value |
|---|---|
| Mounting type | Desk |
| Product colour | White |
Camera
| Specification | Value |
|---|---|
| Lens viewing angle, horizontal | 102.5° |
| Lens viewing angle, vertical | 55.2° |
| Lens viewing angle, diagonal | 122° |
| Tilt angle range | -10 - 90° |
| Pan range | -170 - 170° |
| Camera shutter type | Electronic |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Fixed focal length | 3.18 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 7 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Video formats supported | H.264 |
| Video compression formats | H.264 |
| Supported graphics resolutions | 2560 x 1440 |
| Supported video modes | 1440p |
| Video recording | Yes |
| Smart IR | Yes |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio formats supported | AAC-LC |
| Built-in microphone | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.11n, IEEE 802.11ac |
| Supported network protocols | IPv4, IPv6, DHCP/DHCPv6 Client |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Intelligent Video Surveillance (IVS) system features | Human detection, Moving object |
| Security algorithms | WPA3 |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Remotely operated | Yes |
| Smartphone/tablet remote support | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC, DC |
| AC input voltage | 100 to 240 |
| AC input frequency | 50/60 Hz |
| DC output voltage | 5 |
| DC output current | 2 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
System requirements
| Specification | Value |
|---|---|
| Mobile operating systems supported | iOS, Android |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 114.1 mm |
| Depth | 77.9 mm |
| Height | 77.7 mm |
| Weight | 320 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
