D-Link DCS-6513/EP security camera Dome IP security camera Outdoor

2048 x 1536 pixels

Model DCS-6513/EP

57 specifications

ConnectivityWired
TypeIP security camera
Weight1.53 kg
ColourWhite
Form factorDome
Minimum illumination0 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 1.53 kg
Colour: White
Form factor: Dome
Minimum illumination: 0 lx

Brand: D-Link
Category: Security Camera
Model: DCS-6513/EP
Part number: DCS-6513/EP
Also known as: D-Link DCS-6513/EP security camera Dome IP security camera Outdoor 2048 x 1536 pixels

Specifications

57 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Certification	IK-10 CE FCC CE LVD C-Tick

Design

Specification	Value
Form factor	Dome
Product colour	White
International Protection (IP) code	IP67

Camera

Specification	Value
Minimum illumination	0 lx
Lens viewing angle, vertical	96.4°
Lens viewing angle, diagonal	51.2°

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 2.8 mm (1 / 2.8")

Lens system

Specification	Value
Digital zoom	10x
Focal length range	3 - 9 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	20 m
LED type	IR

Video

Specification	Value
Maximum resolution	2048 x 1536 pixels
Total megapixels	3 MP
Video compression formats	H.264, M-JPEG, MPEG4
Supported graphics resolutions	176 x 144, 320 x 240, 480 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Frame rate	30 fps

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Supported network protocols	IPv6, HTTP / HTTPS, IPv4, Samba, TCP/IP, PPPoE, UDP, ICMP, RTP / RTSP/ RTCP, DHCP client, NTP client (D-Link), DNS, DDNS client (D-Link), SMTP, IGMP, FTP, ONVIF
Cabling technology	10/100Base-T(X)

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Interface	RJ-45

Security

Specification	Value
HTTPS encryption	Yes
IP address filtering	Yes
Motion sensor	Yes

Management features

Specification	Value
Reset button	Yes

Power

Specification	Value
Power source type	PoE
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	10.5 W
DC output voltage	12
DC output current	1.25 A
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-40 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	5 - 95%

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8

Weight & dimensions

Specification	Value
Width	151.8 mm
Depth	127 mm
Height	191.8 mm
Weight	1.53 kg

Packaging content

Specification	Value
Number of cameras	1
Bundled software	D-ViewCam

Other features

Specification	Value
Compliance industry standards	IEEE 802.3af
