D-Link DCS-5000L security camera IP security camera Indoor

640 x 480 pixels

Model DCS-5000LEAN 5706998290922

77 specifications

ConnectivityWired & Wireless
TypeIP security camera
Weight292.8 g
ColourBlack, White
Minimum illumination0 lx
Sensor typeCMOS

See all specifications

Overview

Connectivity: Wired & Wireless
Type: IP security camera
Weight: 292.8 g
Colour: Black, White
Minimum illumination: 0 lx
Sensor type: CMOS

Brand: D-Link
Category: Security Camera
Model: DCS-5000L
Part numbers: DCS-5000L, DCS-5000LX2
EAN / UPC: 5706998290922, 3015220767258
Also known as: D-Link DCS-5000L security camera IP security camera Indoor 640 x 480 pixels

Specifications

77 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
PTZ control	Yes
Day/night mode	Yes
Remote viewing	Yes
Certification	• CE • CE LVD • FCC • C-Tick

Design

Specification	Value
Product colour	Black, White
LED indicators	Yes

Camera

Specification	Value
Minimum illumination	0 lx
Lens viewing angle, horizontal	57°
Lens viewing angle, vertical	42°
Lens viewing angle, diagonal	68°
Tilt angle range	-25 - 95°
Tilt speed	16 °/sec
Pan range	-170 - 170°
Pan speed	16 °/sec
Camera shutter speed	1/15 - 1/15000 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 5 mm (1 / 5")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Digital zoom	4x
Maximum aperture number	2.4
Fixed focal length	2.2 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	8 m
LED type	IR

Video

Specification	Value
Maximum resolution	640 x 480 pixels
Video compression formats	M-JPEG, MPEG
Supported graphics resolutions	160 x 112, 320 x 240, 640 x 480 (VGA)
Frame rate	20 fps
Flip & mirror	Yes
Full HD	No
Image quality adjustment	Brightness, Contrast, Saturation
Text caption overlay	Yes
Time stamp overlay	Yes

Audio

Specification	Value
Audio formats supported	PCM
Built-in microphone	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocols	IPV4, ARP, TCP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP Server, PPPoE, UPnP Port Forwarding, LLTD
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)

Storage

Specification	Value
Built-in HDD	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB port	Yes
Interface	RJ-45/WLAN

Security

Specification	Value
HTTPS encryption	Yes
Motion sensor	Yes
Security algorithms	HTTPS, WEP, WPA, WPA-PSK, WPA2, WPS

Management features

Specification	Value
Web-based management	Yes
Remotely operated	Yes
Reset button	Yes
WPS push button	Yes

Power

Specification	Value
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
DC output voltage	5
DC output current	1.5 A

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	20 - 85%
Storage relative humidity (H-H)	5 - 95%

System requirements

Specification	Value
Mac compatibility	Yes
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 H
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Android, iOS

Weight & dimensions

Specification	Value
Width	116.4 mm
Depth	109.1 mm
Height	133.6 mm
Weight	292.8 g
Width (with stand)	116.4 mm
Depth (with stand)	109.1 mm
Height (with stand)	230 mm

Packaging content

Specification	Value
Number of cameras	1
