D-Link Vigilance 5 Megapixel H.265 Outdoor Bullet Camera

Model DCS-4705EEAN 790069441592

74 specifications

ConnectivityWired
TypeIP security camera
Weight445 g
ColourWhite
Form factorBullet
Minimum illumination0 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 445 g
Colour: White
Form factor: Bullet
Minimum illumination: 0 lx

Brand: D-Link
Category: Security Camera
Model: DCS-4705E
Part number: DCS-4705E
EAN / UPC: 790069441592, 790069441783, 790069446535
Also known as: D-Link Vigilance 5 Megapixel H.265 Outdoor Bullet Camera

Specifications

74 specifications in 17 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Infrared (IR) cut-off filter	Yes

Design

Specification	Value
Form factor	Bullet
Mounting type	Wall
Product colour	White
International Protection (IP) code	IP66

Camera

Specification	Value
Minimum illumination	0 lx
Lens viewing angle, horizontal	90°
Lens viewing angle, vertical	50°
Lens viewing angle, diagonal	104°

Image sensor

Specification	Value
Sensor type	CMOS
Number of sensors	1
Optical sensor size	25.4 / 2.5 mm (1 / 2.5")
Progressive scan	Yes

Lens system

Specification	Value
Number of lenses	1
Zoom capability	Yes
Digital zoom	10x
Maximum aperture number	2
Fixed focal length	2.8 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m
LED type	IR

Video

Specification	Value
Maximum resolution	2592 x 1440 pixels
Total megapixels	5 MP
Video compression formats	H.264, H.265, M-JPEG
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1440 x 1080, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1920
Frame rate	30 fps
Video streaming	Yes
Privacy masking	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet interface type	Fast Ethernet

Storage

Specification	Value
Built-in HDD	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1

Security

Specification	Value
Video motion detection	Yes

Power

Specification	Value
Power source type	AC, PoE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.2 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	59 mm
Depth	164.7 mm
Height	59 mm
Diameter	5.9 cm
Weight	445 g

Packaging data

Specification	Value
Package width	137 mm
Package depth	208 mm
Package height	95 mm
Package weight	766.5 g

Packaging content

Specification	Value
Number of cameras	1

Logistics data

Specification	Value
Master (outer) cases per pallet (air)	40 pc(s)
Master (outer) cases per pallet (sea)	56 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	357.8 kg
Pallet gross weight (sea)	490.1 kg
Pallet gross width	120 cm
Pallet height (air)	138.5 cm
Pallet height (sea)	188.5 cm
Products per pallet (air)	400 pc(s)
Products per pallet (sea)	560 pc(s)
Shipping (inner) case gross weight	8.39 kg
Shipping (inner) case height	25 cm
Shipping (inner) case length	50.8 cm
Shipping (inner) case net weight	7.7 kg
Shipping (inner) case width	29.7 cm
Products per shipping (inner) case	10 pc(s)
