D-Link DCS-2802KT security camera Box IP security camera Indoor & outdoor

DCS-2802KT security camera Box IP security camera Indoor & outdoor

1920 x 1080 pixels Ceiling/Wall/Pole

Model DCS-2802KTEAN 790069439704

71 specifications

ConnectivityWired & Wireless
TypeIP security camera
ColourWhite
Form factorBox
Camera pan controlNo
Sensor typeCMOS

See all specifications

Overview

Connectivity: Wired & Wireless
Type: IP security camera
Colour: White
Form factor: Box
Camera pan control: No
Sensor type: CMOS

Brand: D-Link
Category: Security Camera
Model: DCS-2802KT
Part number: DCS-2802KT
EAN / UPC: 790069439704
Also known as: D-Link DCS-2802KT security camera Box IP security camera Indoor & outdoor 1920 x 1080 pixels Ceiling/Wall/Pole

Specifications

71 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Infrared (IR) cut-off filter	Yes
Certification	CE LVD FCC ICES RCM

Design

Specification	Value
Form factor	Box
Mounting type	Ceiling/Wall/Pole
Product colour	White
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP65
Weatherproof	Yes

Camera

Specification	Value
Camera pan control	No
Camera tilt control	No
Minimum illumination	0 lx
Lens viewing angle, horizontal	115°
Lens viewing angle, vertical	64°
Lens viewing angle, diagonal	135°

Image sensor

Specification	Value
Sensor type	CMOS
Number of sensors	1
Optical sensor size	25.4 / 4 mm (1 / 4")
Progressive scan	Yes

Lens system

Specification	Value
Number of lenses	1
Maximum aperture number	2.2
Fixed focal length	1.9 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	7.5 m
LED type	IR

Video

Specification	Value
Maximum resolution	1920 x 1080 pixels
Total megapixels	2 MP
Video compression formats	H.264, MPEG2
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes	1080p
Frame rate	24 fps
Video streaming	Yes
Text caption overlay	Yes
Time stamp overlay	Yes

Audio

Specification	Value
Built-in speaker(s)	Yes
Audio system	2-way
Audio formats supported	LC-AAC
Built-in microphone	Yes
Audio detection	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocols	IPv4, IPv6, ARP, TCP, UDP, ICMP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Storage

Specification	Value
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB port	Yes

Security

Specification	Value
Alert notification type	Push notification
Motion sensor	Yes
Motion sensor technology	Passive infrared (PIR) sensor
Security algorithms	128-bit AES
Video motion detection	Yes

Power

Specification	Value
Power source type	AC, Battery
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1.88 W
DC output voltage	5
DC output current	2 A

Battery

Specification	Value
Battery technology	Lithium

Operational conditions

Specification	Value
Operating temperature (T-T)	-20 - 45 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	5 - 95%

System requirements

Specification	Value
Mobile operating systems supported	Android, iOS

Sustainability

Specification	Value
Compliance certificates	CE
Sustainability compliance	Yes

Packaging content

Specification	Value
Number of cameras	2
