D-Link DCS-2103 security camera Box IP security camera Indoor

1280 x 800 pixels Desk

Model DCS-2103EAN 790069360077

59 specifications

ConnectivityWired
TypeIP security camera
Weight68 g
ColourWhite
Form factorBox
Minimum illumination1 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 68 g
Colour: White
Form factor: Box
Minimum illumination: 1 lx

Brand: D-Link
Category: Security Camera
Model: DCS-2103
Part number: DCS-2103
EAN / UPC: 790069360077, 790069366888
Also known as: D-Link DCS-2103 security camera Box IP security camera Indoor 1280 x 800 pixels Desk

Specifications

59 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
PTZ control	Yes
Certification	CE, CE LVD, FCC, ICES, C-Tick

Design

Specification	Value
Form factor	Box
Mounting type	Desk
Product colour	White
LED indicators	Power

Camera

Specification	Value
Minimum illumination	1 lx
Lens viewing angle, horizontal	57.8°
Lens viewing angle, vertical	37.8°

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 4 mm (1 / 4")

Lens system

Specification	Value
Digital zoom	10x
Fixed focal length	3.45 mm
Normal focusing range	0.3 m

Night vision

Specification	Value
Night vision	No

Video

Specification	Value
Maximum resolution	1280 x 800 pixels
Total megapixels	1 MP
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes	720p
Frame rate	30 fps

Audio

Specification	Value
Audio system	2-way
Built-in microphone	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Supported network protocols	IPv4, TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP/HTTPS, PPPoE, UPnP, RTP/RTSP/RTCP, 3GPP, IGMP, ONVIF, Samba

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
DC-in jack	Yes
Interface	RJ-45

Security

Specification	Value
Password protection type	Yes
HTTPS encryption	Yes
IP address filtering	Yes
Security algorithms	HTTPS
Video motion detection	Yes

Management features

Specification	Value
Web-based management	Yes

Power

Specification	Value
AC input voltage	5 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	2 W
DC output current	1.2 A
Power over Ethernet (PoE)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	20 - 80%

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x

Weight & dimensions

Specification	Value
Width	58 mm
Depth	30.7 mm
Height	95 mm
Weight	68 g

Packaging content

Specification	Value
Manual	Yes
AC adapter included	Yes
Quick start guide	Yes
User guide	Yes
