InRow RD, 600mm Air Cooled, 380-415V, 50/60Hz, with humidifier
Model ACRD600PEAN 731304326700
27 specifications
- Noise84 dB
- Weight413 kg
- ColourBlack
- Input power20200 W
- Operating temperature (T-T)-20 - 50 °C
- Width600 mm
Overview
- Noise
- 84 dB
- Weight
- 413 kg
- Colour
- Black
- Input power
- 20200 W
- Operating temperature (T-T)
- -20 - 50 °C
- Width
- 600 mm
- Brand
- APC
- Category
- Rack Cooling Equipment
- Model
- ACRD600P
- Part number
- ACRD600P
- EAN / UPC
- 731304326700
- Also known as
- APC InRow RD, 600mm Air Cooled, 380-415V, 50/60Hz, with humidifier
Specifications
27 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Housing colour | Black |
| Rack capacity | 42U |
| Airflow | 1887.8 l/s |
| Humidification capacity | 3000 ml/h |
| Built-in display | Yes |
| Display type | LCD |
| Number of power cords | 1 |
| Noise level | 84 dB |
Power
| Specification | Value |
|---|---|
| Input power | 20200 W |
| Input voltage | 200 - 240 V |
| Input frequency | 50 / 60 Hz |
| Number of input phases | 3 |
| Current | 78 A |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 50 °C |
| Storage temperature (T-T) | 5 - 95 °C |
| Operating altitude | 0 - 3000 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 600 mm |
| Depth | 1070 mm |
| Height | 1991 mm |
| Weight | 413 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1137 mm |
| Package depth | 850 mm |
| Package height | 2166 mm |
| Package weight | 458 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Quick installation guide | Yes |
