Shuttle PC45G power supply unit
250 W 24-pin ATX Flex ATX Silver
Model PC45GPart no. POC-PC45G01EAN 4046047102860
38 specifications
- ColourSilver
- Total power250 W
- Motherboard power connector24-pin ATX
- PurposePC
- Width80 mm
- Sustainability certificatesENERGY STAR
Overview
- Colour
- Silver
- Total power
- 250 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- PC
- Width
- 80 mm
- Sustainability certificates
- ENERGY STAR
- Brand
- Shuttle
- Category
- Power Supply Unit
- Model
- PC45G
- Part number
- POC-PC45G01
- EAN / UPC
- 4046047102860
- Also known as
- Shuttle PC45G power supply unit 250 W 24-pin ATX Flex ATX Silver
Specifications
38 specifications in 9 groups
Power
| Specification | Value |
|---|---|
| Total power | 250 W |
| AC input voltage | 90 - 264 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 3 - 1.5 A |
| Maximum input current (@110V) | +12V,+3.3V,+5V,+5Vsb,-12V |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 216 W |
| Combined power (+5V) | 100 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V) | 17 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2 A |
| Hold time | 17 ms |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage, Overheating |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 3 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| ATX Power connector (24-pin) | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | Flex ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| Compatible products | Shuttle XPC G, G2, G5, G6, ST61G4 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Cooling type | Active |
| Fan diameter | 4 cm |
| Number of fans | 1 fan(s) |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, CB, WEEE, ErP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 150 mm |
| Height | 40 mm |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Country of origin | China |
Other features
| Specification | Value |
|---|---|
| Rise time | 20 ms |
