CLUB3D CSP-X1000CB power supply unit

CLUB3D CSP-X1000CB power supply unit

1000 W 20+4 pin ATX ATX Black, Blue

Model CSP-X1000CBEAN 8717249408727

51 specifications
  • Noise10 dB
  • ColourBlack, Blue
  • Total power1000 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
  • Width150 mm
See all specifications

Overview

Noise
10 dB
Colour
Black, Blue
Total power
1000 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Width
150 mm
Brand
CLUB3D
Model
CSP-X1000CB
Part number
CSP-X1000CB
EAN / UPC
8717249408727
Also known as
CLUB3D CSP-X1000CB power supply unit 1000 W 20+4 pin ATX ATX Black, Blue

Specifications

51 specifications in 9 groups

Power

Total power1000 W
AC input voltage115 - 230 V
AC input frequency50 - 60 Hz
Input current15 A
Maximum input current (@110V)+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)170 W
Combined power (+12V)979 W
Combined power (+5V)170 W
Combined power (-12V)6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)24 A
Max output current (+12V1)38 A
Max output current (+12V2)38 A
Max output current (+12V3)38 A
Max output current (+12V4)38 A
Max output current (+5V)30 A
Max output current (-12V)0.5 A
Max output current (+5Vsb)3 A
Efficiency85%
Power protection featuresOver current, Over power, Over voltage, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of PATA power connectors2
Number of SATA power connectors9
Peripheral (Molex) power connectors (4-pin)5
PCI Express power connectors (6+2 pin)6
CPU power connector (4+4 pin)Yes
ATX power connector (20+4 pin)Yes
Floppy drive power connector2
PCI Express connectorYes
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Bronze
ATX version2.3
EPS version2.92
Noise level10 dB

Design

Product colourBlack, Blue
Cooling typeActive
Fan diameter13.5 cm
Number of fans1 fan(s)
On/off switchYes

Certificates

Compliance certificatesRoHS
CertificationCE, 80Plus Bronze

Weight & dimensions

Width150 mm
Depth165 mm
Height86 mm

Packaging data

ManualYes

Technical details

Sustainability certificatesENERGY STAR

Other features

Dimensions (WxDxH)150 x 165 x 86 mm
Power supply typeAC/DC
