Geist VA7G9201 power distribution unit (PDU) 12 AC outlet(s) 2U
Model VA7G9201EAN 767041037449
20 specifications
- Power7300 W
- TypeSingle-phase
- Weight8.62 kg
- PDU typesMonitored, Switched
- AC outlets quantity12 AC outlet(s)
- LED indicatorsYes
Overview
- Power
- 7300 W
- Type
- Single-phase
- Weight
- 8.62 kg
- PDU types
- Monitored, Switched
- AC outlets quantity
- 12 AC outlet(s)
- LED indicators
- Yes
- Brand
- Vertiv
- Category
- Power Distribution Units (PDUs)
- Model
- VA7G9201
- Part number
- VA7G9201
- EAN / UPC
- 767041037449, 4061471342897
- Also known as
- Vertiv Geist VA7G9201 power distribution unit (PDU) 12 AC outlet(s) 2U
Specifications
20 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| PDU types | Monitored, Switched |
| Type | Single-phase |
| Rack capacity | 2U |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 12 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Specification | Value |
|---|---|
| LED indicators | Yes |
Management features
| Specification | Value |
|---|---|
| Monitoring | Current |
| Management protocols | DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Modbus TCP/IP, Syslog, TACACS+ |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 200 - 240 V |
| Maximum current | 32 A |
| Output voltage | 200 - 240 V |
| Maximum power | 7300 W |
| Power protection features | Over current |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 431.8 mm |
| Depth | 457.2 mm |
| Height | 86.1 mm |
| Weight | 8.62 kg |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | United States |
