Geist BR100-10 power distribution unit (PDU) 12 AC outlet(s) 0U Black
Model BR100-10Part no. 29047VH
25 specifications
- TypeThree-phase
- ColourBlack
- PDU typesSwitched
- AC outlets quantity12 AC outlet(s)
- LED indicatorsYes
- Nominal input voltage200-240/346-415 V
Overview
- Type
- Three-phase
- Colour
- Black
- PDU types
- Switched
- AC outlets quantity
- 12 AC outlet(s)
- LED indicators
- Yes
- Nominal input voltage
- 200-240/346-415 V
- Brand
- Vertiv
- Category
- Power Distribution Units (PDUs)
- Model
- BR100-10
- Part number
- 29047VH
- Also known as
- Vertiv Geist BR100-10 power distribution unit (PDU) 12 AC outlet(s) 0U Black
Specifications
25 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| PDU types | Switched |
| Type | Three-phase |
| Rack capacity | 0U |
| Mounting | Horizontal |
| Product colour | Black |
| On/off switch | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 12 AC outlet(s) |
| Power plug | IEC 60309 |
| AC outlet types | C13 coupler, C19 coupler |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| LED indicators | Yes |
| Cable length | 3 m |
Management features
| Specification | Value |
|---|---|
| Supported network protocols | DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 200-240/346-415 V |
| AC input frequency | 50/60 Hz |
| Maximum current | 20 A |
| Load capacity | 230 VA |
| Power protection features | Over current |
Certificates
| Specification | Value |
|---|---|
| Certification | CE Marked UKCA Marked Complies with IEC 62368-1 (DOC Available) Complies with EN 55032 and EN 55035 RoHS Compliant Cم Mark RCM Mark (EMC Only) China RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 432 mm |
| Depth | 305 mm |
| Height | 44 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 8.16 kg |
