Geist 2XPR183-103D20TL21-SUP power distribution unit (PDU) 18 AC outlet(s) Black
Model 2XPR183-103D20TL21-SUPPart no. 13435
22 specifications
- TypeThree-phase
- ColourBlack
- PDU typesMetered
- AC outlets quantity18 AC outlet(s)
- Cable length3 m
- Nominal input voltage200-240 V
Overview
- Type
- Three-phase
- Colour
- Black
- PDU types
- Metered
- AC outlets quantity
- 18 AC outlet(s)
- Cable length
- 3 m
- Nominal input voltage
- 200-240 V
- Brand
- Vertiv
- Category
- Power Distribution Units (PDUs)
- Model
- 2XPR183-103D20TL21-SUP
- Part number
- 13435
- Also known as
- Vertiv Geist 2XPR183-103D20TL21-SUP power distribution unit (PDU) 18 AC outlet(s) Black
Specifications
22 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| PDU types | Metered |
| Type | Three-phase |
| Mounting | Horizontal |
| Product colour | Black |
| Display | LED |
| On/off switch | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 18 AC outlet(s) |
| Power plug | NEMA L21-30P |
| AC outlet types | NEMA 5-20R |
Features
| Specification | Value |
|---|---|
| Cable length | 3 m |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 200-240 V |
| AC input frequency | 50/60 Hz |
| Maximum current | 30 A |
| Load capacity | 120 VA |
| Power protection features | Over current |
Certificates
| Specification | Value |
|---|---|
| Certification | RoHS Compliant UL & c-UL Listed 60950 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 45 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 431.8 mm |
| Depth | 152.4 mm |
| Height | 86.1 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 8.16 kg |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | United States |
