PDU7C02 power distribution unit (PDU) 7 AC outlet(s) 1U Black
Model PDU7C02EAN 4052792068733
28 specifications
- Power3600 W
- Weight800 g
- ColourBlack
- Rack capacity1U
- AC outlets quantity7 AC outlet(s)
- LED indicatorsYes
Overview
- Power
- 3600 W
- Weight
- 800 g
- Colour
- Black
- Rack capacity
- 1U
- AC outlets quantity
- 7 AC outlet(s)
- LED indicators
- Yes
- Brand
- LogiLink
- Category
- Power Distribution Units (PDUs)
- Model
- PDU7C02
- Part number
- PDU7C02
- EAN / UPC
- 4052792068733
- Also known as
- LogiLink PDU7C02 power distribution unit (PDU) 7 AC outlet(s) 1U Black
Specifications
28 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Mounting | Vertical |
| Housing material | Aluminium |
| Product colour | Black |
| On/off switch | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 7 AC outlet(s) |
| Power plug | Type F |
| AC outlet types | Type F |
Features
| Specification | Value |
|---|---|
| LED indicators | Yes |
| Cable type | H05VVF 3x1.5² |
| International Protection (IP) code | IP20 |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 230 V |
| AC input frequency | 50 Hz |
| Maximum current | 16 A |
| Maximum power | 3600 W |
| Surge energy rating | 375 J |
| Surge protection | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 45 mm |
| Depth | 485 mm |
| Height | 45 mm |
| Weight | 800 g |
| Size (imperial) | 48.3 cm (19") |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 980 g |
| Package width | 515 mm |
| Package depth | 95 mm |
| Package height | 60 mm |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
