PDU31102 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Model PDU31102EAN 649532620388
39 specifications
- TypeSingle-phase
- Weight6.8 kg
- ColourBlack
- PDU typesMonitored
- AC outlets quantity24 AC outlet(s)
- LED indicatorsLink, Status
Overview
- Type
- Single-phase
- Weight
- 6.8 kg
- Colour
- Black
- PDU types
- Monitored
- AC outlets quantity
- 24 AC outlet(s)
- LED indicators
- Link, Status
- Brand
- CyberPower
- Category
- Power Distribution Units (PDUs)
- Model
- PDU31102
- Part number
- PDU31102
- EAN / UPC
- 649532620388
- Also known as
- CyberPower PDU31102 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Specifications
39 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| PDU types | Monitored |
| Type | Single-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Housing material | Steel |
| Product colour | Black |
| Display | LCD |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 24 AC outlet(s) |
| Power plug | NEMA 5–20R |
| AC outlet types | NEMA 5–20R |
| Ethernet LAN (RJ-45) ports | 2 |
| USB ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| LED indicators | Link, Status |
| Cable length | 3 m |
Management features
| Specification | Value |
|---|---|
| Monitoring | Current, Voltage |
| Firmware upgradeable | Yes |
| Firmware upgradeable via | Network, USB |
| Management protocols | UDP, Syslog, CLI, Windows AD |
| Supported network protocols | IPv4, IPv6, HTTP, TLS, DNS, TCP/IP, DHCP, FTP, SNMPv1, NTP, Telnet, SMTP, SNMPv3, HTTPs, SSH, SSL, LDAP(S), RADIUS |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 100 - 120 V |
| AC input frequency | 50 - 60 Hz |
| Maximum current | 30 A |
| Power protection features | Overload |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3500 m |
| Operating temperature (T-T) | 32 - 140 °F |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 56 mm |
| Depth | 48 mm |
| Height | 1664 mm |
| Weight | 6.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Rack mount kit | Yes |
| Packaging content | PDU, 2 Mounting Brackets, 6 (Flat Head M4x5) Bracket Mounting Screws, 6 (M5x12) Rack Mounting Screws/Washers, Cord Retention Tray, 36 Cable Ties, 6 (M3x6) Cord Retention Tray Mounting Screws, RJ45/DB9 Serial Port Connection Cable, Registration and Software Download Cards |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 8.71 kg |
| Package width | 185.4 mm |
| Package depth | 114.3 mm |
| Package height | 1894.8 mm |
