PDU31101 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Model PDU31101EAN 649532620371
29 specifications
- TypeSingle-phase
- Weight6 kg
- ColourBlack
- PDU typesMonitored
- AC outlets quantity24 AC outlet(s)
- Reset buttonYes
Overview
- Type
- Single-phase
- Weight
- 6 kg
- Colour
- Black
- PDU types
- Monitored
- AC outlets quantity
- 24 AC outlet(s)
- Reset button
- Yes
- Brand
- CyberPower
- Category
- Power Distribution Units (PDUs)
- Model
- PDU31101
- Part number
- PDU31101
- EAN / UPC
- 649532620371
- Also known as
- CyberPower PDU31101 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Specifications
29 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| PDU types | Monitored |
| Type | Single-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Housing material | Steel |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 24 AC outlet(s) |
| Power plug | NEMA 5-20P |
| AC outlet types | NEMA L5-20R |
Features
| Specification | Value |
|---|---|
| Reset button | Yes |
| LED indicators | Link, Status |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 100 - 120 V |
| AC input frequency | 50 / 60 Hz |
| Maximum current | 16 A |
| Output voltage | 100 - 120 V |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | FCC Class A, UL60950 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -15 - 65 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 55 mm |
| Depth | 48 mm |
| Height | 1665 mm |
| Weight | 6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 7.9 kg |
| Package width | 185 mm |
| Package depth | 115 mm |
| Package height | 1895 mm |
