CyberPower PDU20BHVIEC8R power distribution unit (PDU) 8 AC outlet(s) 1U Black

CyberPower PDU20BHVIEC8R power distribution unit (PDU) 8 AC outlet(s) 1U Black

Model PDU20BHVIEC8REAN 649532902170

37 specifications

TypeSingle-phase
Weight2 kg
ColourBlack
PDU typesBasic
AC outlets quantity8 AC outlet(s)
Cable length3.05 m

See all specifications

Overview

Type: Single-phase
Weight: 2 kg
Colour: Black
PDU types: Basic
AC outlets quantity: 8 AC outlet(s)
Cable length: 3.05 m

Brand: CyberPower
Category: Power Distribution Units (PDUs)
Model: PDU20BHVIEC8R
Part number: PDU20BHVIEC8R
EAN / UPC: 649532902170, 735858142687, 4712364144745, 6495329021708
Also known as: CyberPower PDU20BHVIEC8R power distribution unit (PDU) 8 AC outlet(s) 1U Black

Specifications

37 specifications in 10 groups

Design

Specification	Value
PDU types	Basic
Type	Single-phase
Rack capacity	1U
Mounting	Horizontal/Vertical
Housing material	Steel
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	8 AC outlet(s)
Power plug	C20 coupler
AC outlet types	C13 coupler, C19 coupler

Features

Specification	Value
Cable length	3.05 m

Power

Specification	Value
Nominal input voltage	200 - 240 V
AC input frequency	50 / 60 Hz
Maximum current	16 A
Nominal output voltage	200 - 240 V
Power protection features	Overload
Surge protection	Yes
Circuit breaker	Yes

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	UL60950, UL62368

Sustainability

Specification	Value
Sustainability compliance	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m

Weight & dimensions

Specification	Value
Width	445 mm
Depth	38.1 mm
Height	44.5 mm
Weight	2 kg
Weight (imperial)	0.907 kg (2 lbs)
Dimensions (W x D x H) (imperial)	444.5 x 38.1 x 44.5 mm (17.5 x 1.5 x 1.75")

Packaging content

Specification	Value
Packaging content	PDU20BHVIEC8R, User's Manual, Product Registration Card, Cord Retention Tray, Mounting Brackets, Cable Ties, Screw Kit

Packaging data

Specification	Value
Package weight	14.9 kg
Package width	530 mm
Package depth	330 mm
Package height	233 mm
