ATEN 20A/16A 8-Outlet 1U Outlet-Metered eco PDU

ATEN 20A/16A 8-Outlet 1U Outlet-Metered eco PDU

Model PE7208G-AX-GEAN 4719264642180

40 specifications
  • Weight2.74 kg
  • ColourBlack
  • PDU typesMetered, Monitored
  • AC outlets quantity8 AC outlet(s)
  • Cable length3 m
  • MonitoringHumidity, Temperature
See all specifications

Overview

Weight
2.74 kg
Colour
Black
PDU types
Metered, Monitored
AC outlets quantity
8 AC outlet(s)
Cable length
3 m
Monitoring
Humidity, Temperature
Brand
ATEN
Model
PE7208G-AX-G
Part number
PE7208G-AX-G
EAN / UPC
4719264642180
Also known as
ATEN 20A/16A 8-Outlet 1U Outlet-Metered eco PDU

Specifications

40 specifications in 10 groups

Design

PDU typesMetered, Monitored
Rack capacity1U
Housing materialMetal
Product colourBlack

Ports & interfaces

AC outlets quantity8 AC outlet(s)
Power plugC20 coupler
AC outlet typesC13 coupler, C19 coupler
Master AC outlets quantity1
Ethernet LAN (RJ-45) ports1

Features

Cable length3 m
Security algorithms802.1x RADIUS, SSL/TLS

Management features

MonitoringHumidity, Temperature
Outlet controlTurn on
Management platformSNMP V1,V2&V3, Telnet
Supported network protocolsTCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, NTP, DNS, Auto Sense, Ping

Power

Nominal input voltage100 - 240 V
AC input frequency50 - 60 Hz
Maximum current16 A
Nominal output voltage100 - 240 V
Load capacity3680 VA

Certificates

Compliance certificatesCE

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width220.4 mm
Depth432.4 mm
Height44 mm
Weight2.74 kg

Packaging data

Package weight4 kg
Package width116 mm
Package depth499 mm
Package height324 mm
Package volume18689.12 cm³

Logistics data

Country of originTaiwan
Master (outer) case net weight9.54 kg
Master (outer) case width388 mm
Master (outer) case length519 mm
Master (outer) case height348 mm
Master (outer) case gross weight12.8 kg
Master (outer) case volume70225.78 cm³
