0U Basic PDU with Surge Protection
Model PE0224SGPart no. PE0224SG-AT-GEAN 4719264649066
36 specifications
- Weight2.05 kg
- ColourBlack
- PDU typesBasic
- AC outlets quantity24 AC outlet(s)
- Cable length3.048 m
- Nominal input voltage100-240 V
Overview
- Weight
- 2.05 kg
- Colour
- Black
- PDU types
- Basic
- AC outlets quantity
- 24 AC outlet(s)
- Cable length
- 3.048 m
- Nominal input voltage
- 100-240 V
- Brand
- ATEN
- Category
- Power Distribution Units (PDUs)
- Model
- PE0224SG
- Part numbers
- PE0224SG-AT-G, PE0224SG
- EAN / UPC
- 4719264649066
- Also known as
- ATEN 0U Basic PDU with Surge Protection
Specifications
36 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| PDU types | Basic |
| Rack capacity | 0U |
| Housing material | Aluminium |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 24 AC outlet(s) |
| Power plug | IEC 320 |
| AC outlet types | C13 coupler, C19 coupler |
Features
| Specification | Value |
|---|---|
| Cable length | 3.048 m |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Maximum current | 16 A |
| Block 1 output current | 10 A |
| Block 2 output current | 16 A |
| Load capacity | 3840 VA |
| Maximum input current per phase | 16 A |
| Surge protection | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 44.4 mm |
| Depth | 966.8 mm |
| Height | 60 mm |
| Weight | 2.05 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 2.81 kg |
| Package width | 145 mm |
| Package depth | 1177 mm |
| Package height | 166 mm |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 2.05 kg |
| Master (outer) case width | 146 mm |
| Master (outer) case length | 1177 mm |
| Master (outer) case height | 166 mm |
| Master (outer) case gross weight | 2.81 kg |
| Products per master (outer) case | 1 pc(s) |
