APC Easy Rack PDU, Switched, 0U, 3 Phase, 11kW: Full Specifications

Overview

Power: 11000 W
Type: Three-phase
Weight: 6.2 kg
Colour: Black
PDU types: Switched
AC outlets quantity: 27 AC outlet(s)

Brand: APC
Category: Power Distribution Units (PDUs)
Model: EPDU1216S
Part number: EPDU1216S
EAN / UPC: 731304428022
Also known as: APC Easy Rack PDU, Switched, 0U, 3 Phase, 11kW, 230V, 16A, 21 C13 and 6 C19 outlets, IEC60309 3P + N + PE inlet

Specifications

43 specifications in 11 groups

Design

Specification	Value
PDU types	Switched
Type	Three-phase
Rack capacity	0U
Mounting	Vertical
Housing material	Aluminium
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	27 AC outlet(s)
Power plug	IEC 60309
AC outlet types	C13 coupler, C19 coupler
Input connection type	IEC 60309 16 A 3P + N + PE

Features

Specification	Value
Daisy chain	Yes
Cable length	2 m

Power

Specification	Value
Nominal input voltage	400 3 phases
AC input frequency	50 - 60 Hz
Maximum current	16 A
Output voltage	230 V
Number of phases	3
Maximum power	11000 W

Certificates

Specification	Value
Compliance certificates	RoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Certification	CE; EAC; RCM; TÜV

Sustainability

Specification	Value
Sustainability compliance	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m

Weight & dimensions

Specification	Value
Width	55 mm
Depth	62 mm
Height	1794 mm
Weight	6.2 kg

Packaging data

Specification	Value
Package weight	7.78 kg
Package width	160 mm
Package depth	110 mm
Package height	1950 mm

Technical details

Specification	Value
Preferred mounting position	no preference
Packaging without single use plastic	No
Sustainable packaging	No
Take-back system	No

Logistics data

Specification	Value
Country of origin	China
Customs product code (TARIC)	8537109899
Total carbon footprint (kg of CO2e)	845.6987954423
