APDU9959EU3 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Model APDU9959EU3EAN 731304356295
36 specifications
- Power3680 W
- TypeSingle-phase
- Weight5.61 kg
- ColourBlack
- PDU typesSwitched
- AC outlets quantity24 AC outlet(s)
Overview
- Power
- 3680 W
- Type
- Single-phase
- Weight
- 5.61 kg
- Colour
- Black
- PDU types
- Switched
- AC outlets quantity
- 24 AC outlet(s)
- Brand
- APC
- Category
- Power Distribution Units (PDUs)
- Model
- APDU9959EU3
- Part number
- APDU9959EU3
- EAN / UPC
- 731304356295
- Also known as
- APC APDU9959EU3 power distribution unit (PDU) 24 AC outlet(s) 0U Black
Specifications
36 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| PDU types | Switched |
| Type | Single-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Product colour | Black |
| Display | LCD |
| On/off switch | No |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 24 AC outlet(s) |
| Power plug | IEC 60309 |
| AC outlet types | C13 coupler, C19 coupler |
Features
| Specification | Value |
|---|---|
| Daisy chain | Yes |
| Cable length | 3 m |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 230, 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Maximum current | 16 A |
| Nominal output voltage | 239 V |
| Output voltage | 230 V |
| Load capacity | 3680 VA |
| Maximum input current per phase | 16 A |
| Maximum total current draw per phase | 16 A |
| Maximum power | 3680 W |
Certificates
| Specification | Value |
|---|---|
| Certification | EAC, EN 55022 class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC part 15 class A, ICES-003, RCM, VDE |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 45 °C |
| Storage temperature (T-T) | -25 - 65 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15240 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 55 mm |
| Depth | 46 mm |
| Height | 1794 mm |
| Weight | 5.61 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 8.59 kg |
| Package width | 165 mm |
| Package depth | 114 mm |
| Package height | 2002 mm |
