NetShelter Rack PDU Advanced, Switched Metered Outlet, 3Phase, 22.1kW
400V 32A or 17.3kW 415V 30A, 48 Outlets, IEC309
Model APDU10350SMEAN 731304439745
31 specifications
- TypeThree-phase
- Weight9.6 kg
- ColourBlack
- AC outlets quantity48 AC outlet(s)
- Nominal input voltage400 V
- Operating temperature (T-T)-5 - 60 °C
Overview
- Type
- Three-phase
- Weight
- 9.6 kg
- Colour
- Black
- AC outlets quantity
- 48 AC outlet(s)
- Nominal input voltage
- 400 V
- Operating temperature (T-T)
- -5 - 60 °C
- Brand
- APC
- Category
- Power Distribution Units (PDUs)
- Model
- APDU10350SM
- Part number
- APDU10350SM
- EAN / UPC
- 731304439745
- Also known as
- APC NetShelter Rack PDU Advanced, Switched Metered Outlet, 3Phase, 22.1kW 400V 32A or 17.3kW 415V 30A, 48 Outlets, IEC309
Specifications
31 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| PDU types | Metered, Metered-by-outlet, Switched |
| Type | Three-phase |
| Rack capacity | 0U |
| Mounting | Vertical |
| Product colour | Black |
| Display | LCD |
| On/off switch | No |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlets quantity | 48 AC outlet(s) |
| Power plug | IEC 60309 |
| AC outlet types | C13 coupler, C15 coupler, C19 coupler, C21 coupler |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 400 V |
| AC input frequency | 50 - 60 Hz |
| Maximum current | 32 A |
| Nominal output voltage | 230 V |
| Output voltage | 230 V |
| Load capacity | 22100 VA |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, CSA C22.2 No 62368-1, EN 62368-1, FCC part 15 subpart B, UKCA, UL 62368-1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 60 °C |
| Storage temperature (T-T) | -25 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 15240 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 56 mm |
| Depth | 75 mm |
| Height | 1780 mm |
| Weight | 9.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 12.6 kg |
| Package width | 262 mm |
| Package depth | 132 mm |
| Package height | 1980 mm |
Logistics data
| Specification | Value |
|---|---|
| Total carbon footprint (kg of CO2e) | 16737.93 |
