APC Rack PDU, Basic, 1U, 30A

APC Rack PDU, Basic, 1U, 30A

208V, (10) C13

Model AP9571AEAN 007313042727

29 specifications

Weight2.55 kg
ColourGrey
Rack capacity1U
Input connection typeNEMA L6-30P
Cable length3.65 m
Nominal input voltage200; 208; 230 V

See all specifications

Overview

Weight: 2.55 kg
Colour: Grey
Rack capacity: 1U
Input connection type: NEMA L6-30P
Cable length: 3.65 m
Nominal input voltage: 200; 208; 230 V

Brand: APC
Category: Power Distribution Units (PDUs)
Model: AP9571A
Part number: AP9571A
EAN / UPC: 007313042727, 731304272755, 4056572606986, 7313042727556
Also known as: APC Rack PDU, Basic, 1U, 30A, 208V, (10) C13

Specifications

29 specifications in 9 groups

Design

Specification	Value
Rack capacity	1U
Product colour	Grey

Ports & interfaces

Specification	Value
Input connection type	NEMA L6-30P

Features

Specification	Value
Cable length	3.65 m

Power

Specification	Value
Nominal input voltage	200; 208; 230 V
AC input frequency	60 Hz
Nominal output voltage	208 V
Output voltage	208 V
Maximum total current draw per phase	24 A

Certificates

Specification	Value
Compliance certificates	RoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Certification	cUL listed; PSE; UL listed

Operational conditions

Specification	Value
Operating temperature (T-T)	-15 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	445 mm
Depth	77 mm
Height	44 mm
Weight	2.55 kg

Technical details

Specification	Value
Halogen free	No
Packaging recycled materials	Recycled cardboard
Preferred mounting position	no preference
Packaging without single use plastic	No
Sustainable packaging	No
Take-back system	No

Logistics data

Specification	Value
Country of origin	India
Customs product code (TARIC)	8544429090
Total carbon footprint (kg of CO2e)	8397.9475761988
