APC Rack PDU, 2G, metered by outlet, with switching, 0U, 30A, 200V and 208V, 21 C13 and 3 C19 sockets

APC Rack PDU, 2G, metered by outlet, with switching, 0U, 30A, 200V and 208V, 21 C13 and 3 C19 sockets

Model AP8641EAN 7313042769754

41 specifications
  • Weight8.23 kg
  • ColourBlack
  • PDU typesSwitched
  • AC outlets quantity24 AC outlet(s)
  • Cable length2.9 m
  • Nominal input voltage200; 208; 230 V
See all specifications

Overview

Weight
8.23 kg
Colour
Black
PDU types
Switched
AC outlets quantity
24 AC outlet(s)
Cable length
2.9 m
Nominal input voltage
200; 208; 230 V
Brand
APC
Model
AP8641
Part number
AP8641
EAN / UPC
7313042769754, 012303055533, 042111829606, 132017657233 +2 more
Also known as
APC Rack PDU, 2G, metered by outlet, with switching, 0U, 30A, 200V and 208V, 21 C13 and 3 C19 sockets

Specifications

41 specifications in 10 groups

Design

PDU typesSwitched
Rack capacity0U
Product colourBlack

Ports & interfaces

AC outlets quantity24 AC outlet(s)
Power plugNEMA L6-30P
Input connection typeNEMA L6-30P

Features

Cable length2.9 m

Power

Nominal input voltage200; 208; 230 V
AC input frequency50 - 60 Hz
Maximum current30 A
Nominal output voltage208 V
Output voltage200 V; 208 V
Maximum total current draw per phase30 A
Power protection featuresOverload

Certificates

Compliance certificatesRoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) complianceYes
CertificationcUL listed; PSE; UL listed; VCCI class A

Operational conditions

Operating temperature (T-T)-5 - 45 °C
Storage temperature (T-T)-25 - 65 °C
Operating relative humidity (H-H)5 - 95%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Weight & dimensions

Width56 mm
Depth51 mm
Height1829 mm
Weight8.23 kg

Packaging data

Package weight10.5 kg
Package width162 mm
Package depth118 mm
Package height2038 mm

Technical details

Halogen freeNo
Packaging recycled materialsRecycled cardboard
Preferred mounting positionno preference
Removable batteryYes
Packaging without single use plasticNo
Sustainable packagingNo
Take-back systemNo

Logistics data

Country of originIndia
Customs product code (TARIC)8537109899
Total carbon footprint (kg of CO2e)3177.7753173235
