APC AP8453 power distribution unit (PDU) 24 AC outlet(s) 0U Black

APC AP8453 power distribution unit (PDU) 24 AC outlet(s) 0U Black

Model AP8453EAN 731304317555

33 specifications

Power7680 W
TypeSingle-phase
Weight8.21 kg
ColourBlack
PDU typesMetered, Metered-by-outlet
AC outlets quantity24 AC outlet(s)

See all specifications

Overview

Power: 7680 W
Type: Single-phase
Weight: 8.21 kg
Colour: Black
PDU types: Metered, Metered-by-outlet
AC outlets quantity: 24 AC outlet(s)

Brand: APC
Category: Power Distribution Units (PDUs)
Model: AP8453
Part number: AP8453
EAN / UPC: 731304317555
Also known as: APC AP8453 power distribution unit (PDU) 24 AC outlet(s) 0U Black

Specifications

33 specifications in 10 groups

Design

Specification	Value
PDU types	Metered, Metered-by-outlet
Type	Single-phase
Rack capacity	0U
Mounting	Vertical
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	24 AC outlet(s)
Power plug	IEC309
AC outlet types	C13 coupler, C19 coupler

Features

Specification	Value
Cable length	3.05 m

Management features

Specification	Value
Monitoring	Current, Power, Voltage

Power

Specification	Value
AC input frequency	50 - 60 Hz
Maximum current	32 A
Nominal output voltage	230 V
Load capacity	7680 VA
Maximum input current per phase	32 A
Maximum total current draw per phase	32 A
Maximum power	7680 W

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	EN 55022 A, EN 55024, EN 61000-3-2, EN 61000-3-3, VDE

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m

Weight & dimensions

Specification	Value
Width	56 mm
Depth	51 mm
Height	1829 mm
Weight	8.21 kg

Packaging data

Specification	Value
Package weight	10.5 kg
Package width	163 mm
Package depth	117 mm
Package height	2037 mm

Logistics data

Specification	Value
Total carbon footprint (kg of CO2e)	5046.47
