APC AP7850B power distribution unit (PDU) 16 AC outlet(s) 0U Black

APC AP7850B power distribution unit (PDU) 16 AC outlet(s) 0U Black

Model AP7850BEAN 731304331537

35 specifications

Power2300 W
Weight3.07 kg
ColourBlack
PDU typesMetered
AC outlets quantity16 AC outlet(s)
LED indicatorsYes

See all specifications

Overview

Power: 2300 W
Weight: 3.07 kg
Colour: Black
PDU types: Metered
AC outlets quantity: 16 AC outlet(s)
LED indicators: Yes

Brand: APC
Category: Power Distribution Units (PDUs)
Model: AP7850B
Part number: AP7850B
EAN / UPC: 731304331537
Also known as: APC AP7850B power distribution unit (PDU) 16 AC outlet(s) 0U Black

Specifications

35 specifications in 9 groups

Design

Specification	Value
PDU types	Metered
Rack capacity	0U
Mounting	Vertical
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	16 AC outlet(s)
Power plug	C14 coupler
AC outlet types	C13 coupler

Features

Specification	Value
LED indicators	Yes
Cable length	3.05 m

Management features

Specification	Value
Monitoring	Current, Power, Voltage

Power

Specification	Value
Nominal input voltage	200-250 V
AC input frequency	47/63 Hz
Maximum current	10 A
Nominal output voltage	230 V
Load capacity	2300 VA
Maximum input current per phase	10 A
Maximum total current draw per phase	10 A
Maximum power	2300 W

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	CE, GOST, VDE

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Operating temperature (T-T)	23 - 113 °F

Weight & dimensions

Specification	Value
Width	56 mm
Depth	44 mm
Height	1245 mm
Weight	3.07 kg

Packaging data

Specification	Value
Package weight	3.98 kg
Package width	387 mm
Package depth	323 mm
Package height	2134 mm
