APC AP6002A power distribution unit (PDU) 16 AC outlet(s) Black

APC AP6002A power distribution unit (PDU) 16 AC outlet(s) Black

Model AP6002AEAN 731304327639

28 specifications

Weight2.78 kg
ColourBlack
PDU typesBasic
AC outlets quantity16 AC outlet(s)
Nominal input voltage208 V
Operating temperature (T-T)0 - 50 °C

See all specifications

Overview

Weight: 2.78 kg
Colour: Black
PDU types: Basic
AC outlets quantity: 16 AC outlet(s)
Nominal input voltage: 208 V
Operating temperature (T-T): 0 - 50 °C

Brand: APC
Category: Power Distribution Units (PDUs)
Model: AP6002A
Part number: AP6002A
EAN / UPC: 731304327639
Also known as: APC AP6002A power distribution unit (PDU) 16 AC outlet(s) Black

Specifications

28 specifications in 8 groups

Design

Specification	Value
PDU types	Basic
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	16 AC outlet(s)
AC outlet types	C13 coupler, C19 coupler
Input connection type	NEMA L6-30P

Power

Specification	Value
Nominal input voltage	208 V
AC input frequency	50 - 60 Hz
Maximum current	30 A
Maximum input current per phase	30 A
Maximum total current draw per phase	30 A
Power protection features	Overload

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	cUL, UL

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-15 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m

Weight & dimensions

Specification	Value
Width	56 mm
Depth	47 mm
Height	833 mm
Weight	2.78 kg

Packaging content

Specification	Value
Packaging content	Installation guide, Safety guide

Packaging data

Specification	Value
Package weight	3.24 kg
Package width	156 mm
Package depth	137 mm
Package height	966 mm
