IGG320174pack N100
3.4 GHz 39.6 cm (15.6") 1920 x 1080 pixels Touchscreen White
Model IGG320174packPart no. IGG320174PACKEAN 2517102511269
60 specifications
- Display39.6 cm (15.6")
- Resolution1920 x 1080 pixels
- ProcessorIntel® N
- Memory8 GB
- Storage128 GB
- OSWindows 10 IoT
Overview
- Display
- 39.6 cm (15.6")
- Resolution
- 1920 x 1080 pixels
- Processor
- Intel® N
- Memory
- 8 GB
- Storage
- 128 GB
- OS
- Windows 10 IoT
- Brand
- iggual
- Category
- POS System
- Model
- IGG320174pack
- Part number
- IGG320174PACK
- EAN / UPC
- 2517102511269
- Also known as
- iggual IGG320174pack N100 3.4 GHz 39.6 cm (15.6") 1920 x 1080 pixels Touchscreen White
Specifications
60 specifications in 15 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | Yes |
| Display type | LCD |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 1200:1 |
| Display brightness | 300 cd/m² |
| Response time | 5 ms |
| Touchscreen technology | Capacitive |
| Viewing angle, horizontal | 89° |
| Viewing angle, vertical | 89° |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® N |
| Processor model | N100 |
| Processor frequency | 3.4 GHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 128 GB |
| Storage media | SSD |
| SSD interface | mSATA |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Bluetooth | No |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Line-in | Yes |
| Line-out | Yes |
| RS-232 ports | 1 |
| RJ-11 ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Built-in cash drawer | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 IoT |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 5 A |
| Power consumption (typical) | 60 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 135 °C |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal transfer |
| Print speed | 230 mm/sec |
| Print resolution | 203 x 203 DPI |
| Maximum printing width | 7.2 cm |
| Maximum roll diameter | 8.3 cm |
| Built-in barcodes | CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E |
| Buffer size | 64 KB |
| Internal memory (printer) | 0.256 MB |
| Autocutter | Yes |
Packaging content
| Specification | Value |
|---|---|
| POS printer included | Yes |
| Power adapter included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
