Shuttle P9000XA 3865U

P9000XA 3865U

1.8 GHz All-in-One 49.5 cm (19.5") 1600 x 900 pixels Touchscreen Black

Model P9000XAPart no. PAC-P90U001EAN 4046047103423

75 specifications

Display49.5 cm (19.5")
Resolution1600 x 900 pixels
ProcessorIntel® Celeron®
Memory4 GB
Storage500 GB
OSNo

See all specifications

Overview

Display: 49.5 cm (19.5")
Resolution: 1600 x 900 pixels
Processor: Intel® Celeron®
Memory: 4 GB
Storage: 500 GB
OS: No

Brand: Shuttle
Category: POS System
Model: P9000XA
Part number: PAC-P90U001
EAN / UPC: 4046047103423
Also known as: Shuttle P9000XA 3865U 1.8 GHz All-in-One 49.5 cm (19.5") 1600 x 900 pixels Touchscreen Black

Specifications

75 specifications in 20 groups

Display

Specification	Value
Display diagonal	49.5 cm (19.5")
Display resolution	1600 x 900 pixels
Touchscreen	Yes
Display type	LCD
Aspect ratio	16:9
Touchscreen technology	Capacitive

Processor

Specification	Value
Processor family	Intel® Celeron®
Processor model	3865U
Processor cores	2
Processor threads	2
Processor frequency	1.8 GHz
Processor cache	2 MB
System bus rate	4 GT/s

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Number of memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	2133 MHz

Storage

Specification	Value
Total storage capacity	500 GB
Storage media	HDD
Storage media type	HDD
HDD capacity	500 GB
HDD interface	SATA
HDD size	2.5"

Graphics

Specification	Value
Graphics card manufacturer	Intel
Graphics card	HD Graphics 610

Features

Specification	Value
Certification	CE, RED, FCC, RCM, VCCI, CB, ETL, RoHS, ErP Lot3
Country of origin	China

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
Line-out	Yes
Microphone in	Yes
Serial ports quantity	2
Parallel ports quantity	1
DC-in jack	Yes

Design

Specification	Value
Chassis type	All-in-One
Product colour	Black

Software

Specification	Value
Operating system installed	No
Windows operating systems supported	Windows 10

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	19 V
AC adapter output current	3.42 A
Power supply	65 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C

Ergonomics

Specification	Value
Wall mountable	Yes
VESA mounting	Yes
Panel mounting interface	100 x 100 mm

Weight & dimensions

Specification	Value
Width	487 mm
Depth	44 mm
Height	321 mm
Weight	4.29 kg

Packaging data

Specification	Value
Package weight	5.62 kg

Packaging content

Specification	Value
Manual	Yes
Cables included	AC
Quick start guide	Yes
Power adapter included	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Logistics data

Specification	Value
Harmonized System (HS) code	84714100
