POS P520
Model POS P520EAN 4046047103836
74 specifications
- Display39.6 cm (15.6")
- Resolution1920 x 1080 pixels
- ProcessorIntel® Celeron®
- Memory4 GB
- Storage120 GB
- OSNo
Overview
- Display
- 39.6 cm (15.6")
- Resolution
- 1920 x 1080 pixels
- Processor
- Intel® Celeron®
- Memory
- 4 GB
- Storage
- 120 GB
- OS
- No
- Brand
- Shuttle
- Category
- POS System
- Model
- POS P520
- Part number
- POS P520
- EAN / UPC
- 4046047103836
- Also known as
- Shuttle All-In-One System POS P520, Intel Celeron 5205U, 4GB , 120GB SSD, 15.6" Multi-Touch-Screen, fanless, 24/7 permanent operation
Specifications
74 specifications in 21 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | Yes |
| Display type | IPS |
| Aspect ratio | 16:9 |
| Display brightness | 250 cd/m² |
| Touchscreen technology | Capacitive |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | 5205U |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 1.9 GHz |
| Processor cache | 2 MB |
| System bus rate | 4 GT/s |
| Processor ARK ID | 197890 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 120 GB |
| Storage media | SSD |
| Number of storage drives supported | 2 |
| NVMe | Yes |
| SSD capacity | 120 GB |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| Graphics card manufacturer | Intel |
| Graphics card | UHD Graphics |
Features
| Specification | Value |
|---|---|
| Certification | RCM, VCCI, BSMI |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Line-in | Yes |
| Line-out | Yes |
| Microphone in | Yes |
| Serial ports quantity | 2 |
| DC-in jack | Yes |
Design
| Specification | Value |
|---|---|
| Chassis type | All-in-One |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Linux operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.42 A |
| Power supply | 65 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 393.6 mm |
| Depth | 272.5 mm |
| Height | 39.8 mm |
| Weight | 3.25 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package weight | 4.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Quick start guide | Yes |
| Power adapter included | Yes |
Security
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, ErP |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, UKCA |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
