Capture CA-SY-10122 POS system J1900: Full Specifications

Overview

Display: 38.1 cm (15")
Resolution: 1024 x 768 pixels
Processor: Intel® Celeron®
Memory: 8 GB
Storage: 128 GB
OS: Windows 10 IoT

Brand: Capture
Category: POS System
Model: CA-SY-10122
Part number: CA-SY-10122
EAN / UPC: 5706998416230, 5706998572219
Also known as: Capture CA-SY-10122 POS system J1900 2 GHz 38.1 cm (15") 1024 x 768 pixels Touchscreen Black

Specifications

49 specifications in 17 groups

Display

Specification	Value
Display diagonal	38.1 cm (15")
Display resolution	1024 x 768 pixels
Touchscreen	Yes
Display type	LCD
Display brightness	300 cd/m²
Touchscreen technology	Projected capacitive system

Processor

Specification	Value
Processor family	Intel® Celeron®
Processor model	J1900
Processor frequency	2 GHz
Processor cache	2 MB

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	DDR3L-SDRAM
Memory slots type	SO-DIMM
Memory clock speed	1333 MHz

Storage

Specification	Value
Total storage capacity	128 GB
Storage media type	SSD

Graphics

Specification	Value
Graphics card manufacturer	Intel
Graphics card	HD Graphics

Features

Specification	Value
Certification	CE, FCC, WEEE, RoHS

Multimedia

Specification	Value
Built-in speaker(s)	Yes

Network

Specification	Value
Ethernet LAN	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	5
VGA (D-Sub) ports quantity	1
Serial ports quantity	6
Parallel ports quantity	1
RJ-11 ports quantity	1

Design

Specification	Value
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 10 IoT
Operating system architecture	64-bit

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	12 V

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 85%
Storage temperature (T-T)	-20 - 55 °C

Ergonomics

Specification	Value
Tilt angle range	15 - 85°
Wall mountable	Yes
VESA mounting	Yes

Weight & dimensions

Specification	Value
Width	355 mm
Depth	205 mm
Height	303 mm
Weight	5 kg

Packaging data

Specification	Value
Package width	290 mm
Package depth	490 mm
Package height	420 mm
Package weight	6.9 kg

Logistics data

Specification	Value
Harmonized System (HS) code	84715000
