Zebra ZP 505

Zebra ZP 505

Model ZP 505Part no. ZP505

39 specifications
  • Memory0.008 GB
  • ConnectivityWired
  • TypePOS printer
  • Weight2.1 kg
  • ColourBlack, Grey
  • Print technologyDirect thermal
See all specifications

Overview

Memory
0.008 GB
Connectivity
Wired
Type
POS printer
Weight
2.1 kg
Colour
Black, Grey
Print technology
Direct thermal
Brand
Zebra
Category
POS Printer
Model
ZP 505
Part number
ZP505
Also known as
Zebra ZP 505 203 x 203 DPI Wired Direct thermal POS printer

Specifications

39 specifications in 11 groups

Printing

Print technologyDirect thermal
TypePOS printer
Maximum resolution203 x 203 DPI
Print speed127 mm/sec

Paper handling

Maximum media length99.1 cm
Maximum printing width10.4 cm
Maximum roll diameter12.7 cm
Media thickness0.076 - 0.191 mm

Ports & interfaces

Connectivity technologyWired
Serial interfaceYes
Serial interface typeRS-232
Parallel ports quantity1
Serial ports quantity1
Standard interfacesRS-232

Network

Ethernet LANNo
Wi-FiNo

Features

Built-in barcodesCode 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC39
Page description languagesZPL II
Flash memory2 MB
Linear (1D) barcodes supportedCodabar, Code 11, Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Planet, POSTNET, Plessey, U.P.C.
RAM capacity0.008 GB
Ribbon size81.3mm x 300/450m
SafetyCOC
CertificationUL, c-UL, FCC, CE, VCCI, C-Tick, CCC, NOM, IRAM, GOST-R, UC-IEE

Design

Product colourBlack, Grey

Power

Power source typeAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power supply typeAC

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)5 - 41 °C
Storage relative humidity (H-H)5 - 95%
Storage temperature (T-T)-40 - 60 °C

System requirements

Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 95, Windows 98, Windows ME, Windows NT, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight & dimensions

Width181 mm
Depth216 mm
Height191 mm
Weight2.1 kg

Packaging content

Drivers includedYes

Energy efficiency

ENERGY STAR certified

Imaging equipment · model ZP450 · certified Oct 16, 2013 · United States, Switzerland, Taiwan, Japan, Canada

Sleep-mode power2.16 W
Standby power0.13 W
