ILP-80 Portable BT
Model ILP-80 Portable BTPart no. L8070USUBTEAN 8437019184704
42 specifications
- Display3.3 cm (1.3")
- Resolution128 x 64 pixels
- Memory8 MB
- Battery2500 mAh
- ConnectivityWired & Wireless
- TypeMobile printer
Overview
- Display
- 3.3 cm (1.3")
- Resolution
- 128 x 64 pixels
- Memory
- 8 MB
- Battery
- 2500 mAh
- Connectivity
- Wired & Wireless
- Type
- Mobile printer
- Brand
- Premier
- Category
- POS Printer
- Model
- ILP-80 Portable BT
- Part number
- L8070USUBT
- EAN / UPC
- 8437019184704
- Also known as
- Premier ILP-80 Portable BT Wired & Wireless Direct thermal Mobile printer
Specifications
42 specifications in 11 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Direct thermal |
| Type | Mobile printer |
| Number of printable dots | 8 dot |
| Print speed | 70 mm/sec |
| Printing characters | 2D barcode, Barcode, Text |
Paper handling
| Specification | Value |
|---|---|
| Maximum media length | 177.8 cm |
| Maximum printing width | 7.2 cm |
| Maximum roll diameter | 5 cm |
| Printing media thickness | 60 - 80 µm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| USB port | Yes |
| Serial interface | No |
| Bluetooth | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), China post, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, Interleaved 2/5, MSI, MaxiCode, PDF417, PLESSEY, POSTNET, Plessey, QR Code, UPC-A |
| Internal memory | 8 MB |
| Storage media | Flash |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 4 GB |
| Built-in sensors details | Gap sensor, Printer Head opened sensor, Black mark sensor, Paper end sensor |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Built-in display | Yes |
| Display | LED |
| Colour display | No |
| Display resolution | 128 x 64 pixels |
| Display diagonal | 3.3 cm (1.3") |
Power
| Specification | Value |
|---|---|
| Power source type | Battery, DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Battery voltage | 7.4 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 25 - 85% |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 124 mm |
| Depth | 61 mm |
| Height | 108 mm |
| Weight | 357 g |
Battery
| Specification | Value |
|---|---|
| Battery capacity | 2500 mAh |
