TM-U220PB (057): Parallel, PS, EDG
Model TM-U220PBPart no. C31C517057EAN 5054629537886
50 specifications
- ConnectivityWired
- TypePOS printer
- Weight2.5 kg
- ColourDark Grey
- Print technologyDot matrix
- Maximum roll diameter8.3 cm
Overview
- Connectivity
- Wired
- Type
- POS printer
- Weight
- 2.5 kg
- Colour
- Dark Grey
- Print technology
- Dot matrix
- Maximum roll diameter
- 8.3 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-U220PB
- Part number
- C31C517057
- EAN / UPC
- 5054629537886, 3540260017204, 4058154268148, 5711045218125 +1 more
- Also known as
- Epson TM-U220PB (057): Parallel, PS, EDG
Specifications
50 specifications in 16 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Dot matrix |
| Type | POS printer |
| Print speed | 4 lps |
| Character density | 16 cpi |
| Character size | 1.6 x 3.1 mm |
Paper handling
| Specification | Value |
|---|---|
| Maximum roll diameter | 8.3 cm |
| Supported paper width | 76, 69.5, 57.5 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Parallel connector | Yes |
| Interface | Drawer kick-out, Bidirectional parallel |
| Standard interfaces | Parallel |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Sound pressure level (printing) | 64 dB |
| Mean time between failures (MTBF) | 180000 h |
| Autocutter durability | 0.8 million cuts |
| Country of origin | Spain |
| Safety | UL, CSA, TÜV (EN60950) |
| Standard media sizes | 63 / 57 /47 mm |
Design
| Specification | Value |
|---|---|
| Product colour | Dark Grey |
Power
| Specification | Value |
|---|---|
| AC input voltage | 24 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -10 - 50 °C |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 2000, XP, Vista |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 248 mm |
| Height | 139 mm |
| Weight | 2.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 302 mm |
| Package depth | 326 mm |
| Package height | 217 mm |
| Package weight | 3.79 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Print technology
| Specification | Value |
|---|---|
| Column capacity | 40 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Products per pallet | 72 pc(s) |
| Products per pallet layer | 8 pc(s) |
| Pallet gross width | 120 cm |
| Pallet gross height | 100 cm |
| Products per pallet (UK) | 108 pc(s) |
| Products per pallet layer (UK) | 12 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.25 m |
Technical details
| Specification | Value |
|---|---|
| Box contents | AC adapter, C, Main unit, Ribbon, Roll paper, User manual |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 160 x 248 x 138.5 mm |
| Electromagnetic compatibility | VCCI class A, FCC class A, CE marking, AS / NZS 3548 class B |
| Mean cycles between failures (MCBF) | 18000000 |
