TM-U220IIB (141): Ethernet, PS, NE sensor, ECW, UK
Model TM-U220IIB (141): Ethernet, PS, NE sensor, ECW, UKPart no. C31CL27141A0EAN 8715946737102
36 specifications
- Weight2.5 kg
- ColourWhite
- Print technologyDot matrix
- Page description languagesESC/POS
- Operating relative humidity (H-H)10 - 90%
- Width160 mm
Overview
- Weight
- 2.5 kg
- Colour
- White
- Print technology
- Dot matrix
- Page description languages
- ESC/POS
- Operating relative humidity (H-H)
- 10 - 90%
- Width
- 160 mm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-U220IIB (141): Ethernet, PS, NE sensor, ECW, UK
- Part number
- C31CL27141A0
- EAN / UPC
- 8715946737102
- Also known as
- Epson TM-U220IIB (141A0): Ethernet, PS, NE sensor, ECW, UK Security
Specifications
36 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Dot matrix |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | Drawer kick-out, USB 2.0-A, Ethernet interface (100 Base-TX / 10 Base-T) |
Features
| Specification | Value |
|---|---|
| Page description languages | ESC/POS |
| Sound pressure level (printing) | 64 dB |
| Mean time between failures (MTBF) | 180000 h |
| Cutter | Yes |
| Autocutter durability | 0.8 million cuts |
Design
| Specification | Value |
|---|---|
| Product colour | White |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -10 - 50 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 248 mm |
| Height | 139 mm |
| Weight | 2.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 300 mm |
| Package depth | 330 mm |
| Package height | 220 mm |
| Package weight | 3.88 kg |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 72 pc(s) |
| Products per pallet layer | 8 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.13 m |
| Products per pallet (UK) | 108 pc(s) |
| Products per pallet layer (UK) | 12 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.13 m |
Technical details
| Specification | Value |
|---|---|
| Technology | Serial Impact Dot Matrix |
| Voltage | 24 V |
| Font styles | ANK, Traditional Chinese, Simplified Chinese |
| Box contents | AC adapter, C, Main unit, Ribbon, Roll paper, User manual |
| Paper size roll paper | 76.00 ± 0.50 (W) mm x dia 83.00 mm,<br>69.50 ± 0.50 (W) mm x dia 83.00 mm,<br>57.50 ± 0.50 (W) mm x dia 83.00 mm |
| Power consumption | Printing: Appx.31 W, Standby: Appx.2 W |
Other features
| Specification | Value |
|---|---|
| Buffer size | 20 KB |
