TM-T88VII-612
180 x 180 DPI Wired Thermal POS printer
Model TM-T88VII-612Part no. C31CJ57612
39 specifications
- ConnectivityWired
- TypePOS printer
- Weight1.6 kg
- ColourBlack
- Print technologyThermal
- Maximum roll diameter8.3 cm
Overview
- Connectivity
- Wired
- Type
- POS printer
- Weight
- 1.6 kg
- Colour
- Black
- Print technology
- Thermal
- Maximum roll diameter
- 8.3 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-T88VII-612
- Part number
- C31CJ57612
- Also known as
- Epson TM-T88VII-612 180 x 180 DPI Wired Thermal POS printer
Specifications
39 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal |
| Type | POS printer |
| Maximum resolution | 180 x 180 DPI |
| Print speed | 500 mm/sec |
Paper handling
| Specification | Value |
|---|---|
| Maximum roll diameter | 8.3 cm |
| Media thickness | 48 - 80 mm |
| Printing media thickness | 48 - 80 µm |
| Supported paper width | 80 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB port | Yes |
| USB connector | USB Type-A / USB Type-B |
| Serial interface | Yes |
| Near Field Communication (NFC) | Yes |
| Optional connectivity | Wireless LAN |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Built-in barcodes | AZTECCODE, Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1-128, PDF417, UPC-A, UPC-E |
| Sound pressure level (printing) | 52 dB |
| Sound pressure level (standby) | 52 dB |
| Mean time between failures (MTBF) | 360000 h |
| Autocutter durability | 3 million cuts |
| Paper save function | Yes |
| Mounting position | Horizontal/Vertical |
| Print head life | 200 km |
| Wall mountable | Yes |
| Certification | CE |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (printing) | 27.6 W |
| AC input voltage | 24 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 45 °C |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 145 mm |
| Depth | 195 mm |
| Height | 148 mm |
| Weight | 1.6 kg |
Other features
| Specification | Value |
|---|---|
| Buffer size | 4 KB |
| Mean cycles between failures (MCBF) | 70000000 |
