TM-T83III-561
203 x 203 DPI Wired Thermal POS printer
Model TM-T83III-561Part no. C31CH26561
25 specifications
- ConnectivityWired
- TypePOS printer
- Weight1.5 kg
- ColourBlack
- Print technologyThermal
- Maximum printing width8 cm
Overview
- Connectivity
- Wired
- Type
- POS printer
- Weight
- 1.5 kg
- Colour
- Black
- Print technology
- Thermal
- Maximum printing width
- 8 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-T83III-561
- Part number
- C31CH26561
- Also known as
- Epson TM-T83III-561 203 x 203 DPI Wired Thermal POS printer
Specifications
25 specifications in 9 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal |
| Type | POS printer |
| Maximum resolution | 203 x 203 DPI |
Paper handling
| Specification | Value |
|---|---|
| Maximum printing width | 8 cm |
| Maximum roll diameter | 8 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Built-in barcodes | Code 93, Code-128 Codabar Library, GS1 DataBar Limited, UPC-A, CODABAR (NW-7), GS1-128, UPC-E, EAN13, Code 39, EAN8, ITF |
| Mean time between failures (MTBF) | 360000 h |
| Cutter | Yes |
| Autocutter durability | 1.5 million cuts |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (printing) | 28.7 W |
| AC input voltage | 100 - 230 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 149 mm |
| Depth | 192 mm |
| Height | 140 mm |
| Weight | 1.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Cables included | Serial, USB |
