Epson TM-T20 (011)
Model TM-T20 (011)Part no. C31CB10011EAN 5712505047903
49 specifications
- ConnectivityWired
- TypePOS printer
- Weight1.7 kg
- ColourDark Grey
- Print technologyThermal
- Maximum roll diameter8.3 cm
Overview
- Connectivity
- Wired
- Type
- POS printer
- Weight
- 1.7 kg
- Colour
- Dark Grey
- Print technology
- Thermal
- Maximum roll diameter
- 8.3 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-T20 (011)
- Part number
- C31CB10011
- EAN / UPC
- 5712505047903, 8715946468198
- Also known as
- Epson TM-T20 (011): USB, PS, EDG, UK
Specifications
49 specifications in 13 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal |
| Type | POS printer |
| Maximum resolution | 203 x 203 DPI |
| Print speed | 150 mm/sec |
| Character density | 22.6 cpi |
| Character size | 0.88 x 2.13 mm |
Paper handling
| Specification | Value |
|---|---|
| Maximum roll diameter | 8.3 cm |
| Supported paper width | 80 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Interface | Drawer kick-out, USB 2.0 |
| Standard interfaces | RS-232 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Sound pressure level (printing) | 55 dB |
| Mean time between failures (MTBF) | 360000 h |
| Autocutter durability | 1.5 million cuts |
| Country of origin | China |
| Certification | CE marking, TÜV, GOST-R, Energy Star |
Design
| Specification | Value |
|---|---|
| Product colour | Dark Grey |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power supply type | AC |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 45 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -10 - 50 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 199 mm |
| Height | 146 mm |
| Weight | 1.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Cables included | AC |
| Quantity per pack | 1 pc(s) |
| Package width | 195 mm |
| Package depth | 235 mm |
| Package height | 230 mm |
| Package weight | 2.42 kg |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 128 pc(s) |
| Products per pallet layer | 16 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 199 cm |
| Products per pallet (UK) | 192 pc(s) |
| Products per pallet layer (UK) | 24 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 199 cm |
Technical details
| Specification | Value |
|---|---|
| Box contents | 58-mm width paper guide plate, Driver and utilities, Main unit, Power cable, Power switch cover, Rubber feet, Setup guide, Thermal roll paper, USB cable, User manual (CD), Wall hanging bracket |
Other features
| Specification | Value |
|---|---|
| LED indicators | Yes |
