TM-M30IIH-021
203 x 203 DPI Wired Thermal POS printer
Model TM-M30IIH-021Part no. C31CH92A9961
32 specifications
- ConnectivityWired
- TypePOS printer
- Weight1.3 kg
- ColourBlack
- Print technologyThermal
- Maximum printing width7.95 cm
Overview
- Connectivity
- Wired
- Type
- POS printer
- Weight
- 1.3 kg
- Colour
- Black
- Print technology
- Thermal
- Maximum printing width
- 7.95 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- TM-M30IIH-021
- Part number
- C31CH92A9961
- Also known as
- Epson TM-M30IIH-021 203 x 203 DPI Wired Thermal POS printer
Specifications
32 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal |
| Type | POS printer |
| Maximum resolution | 203 x 203 DPI |
| Print speed | 250 mm/sec |
Paper handling
| Specification | Value |
|---|---|
| Maximum printing width | 7.95 cm |
| Maximum roll diameter | 8.3 cm |
| Printing media thickness | 48 - 80 µm |
| Roll core diameter (max) | 1.8 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB port | Yes |
| USB connector | USB Type-A / USB Type-B |
| Serial interface | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Built-in barcodes | CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, UPC-A, UPC-E |
| Mean time between failures (MTBF) | 360000 h |
| Cutter | Yes |
| Autocutter durability | 2.2 million cuts |
| Receive buffer | 4 KB |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (printing) | 32.4 W |
| AC input voltage | 115 V |
| AC input frequency | 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 45 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 127 mm |
| Depth | 127 mm |
| Height | 135 mm |
| Weight | 1.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Cables included | AC |
