EU-M30 (002)
Model EU-M30 (002)Part no. C31CK01002EAN 8715946700137
49 specifications
- ConnectivityWired & Wireless
- TypePOS printer
- Weight1.3 kg
- ColourBlack
- Print technologyThermal
- Maximum roll diameter8.3 cm
Overview
- Connectivity
- Wired & Wireless
- Type
- POS printer
- Weight
- 1.3 kg
- Colour
- Black
- Print technology
- Thermal
- Maximum roll diameter
- 8.3 cm
- Brand
- Epson
- Category
- POS Printer
- Model
- EU-M30 (002)
- Part number
- C31CK01002
- EAN / UPC
- 8715946700137
- Also known as
- Epson EU-m30 (002): USB + Serial, NES, Black, No PSU, No Cable
Specifications
49 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal |
| Type | POS printer |
| Maximum resolution | 203 x 203 DPI |
| Print speed (receipt) | 250 mm/sec |
| Printing characters | Text, Graphic, Barcode |
| Character sets | ANK |
Paper handling
| Specification | Value |
|---|---|
| Maximum roll diameter | 8.3 cm |
| Supported paper width | 58 mm - 80 mm (Breite) |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| USB port | Yes |
| Serial interface | Yes |
| Near Field Communication (NFC) | Yes |
| Interface | USB 2.0, RS-232C |
Features
| Specification | Value |
|---|---|
| Sound pressure level (printing) | 55 dB |
| Mean time between failures (MTBF) | 360000 h |
| Half-cutter | Yes |
| Autocutter durability | 1.5 million cuts |
| Country of origin | Philippines |
| Mounting position | Horizontal |
| Print head life | 150 km |
| Built-in sensors details | Paper End Sensor, Papier-Sensor |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power plug type | Type C |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 45 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
System requirements
| Specification | Value |
|---|---|
| Pre-installed software | TMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 127 mm |
| Depth | 131 mm |
| Height | 127 mm |
| Weight | 1.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 195 mm |
| Package depth | 235 mm |
| Package height | 220 mm |
| Package weight | 1.66 kg |
Print technology
| Specification | Value |
|---|---|
| Column capacity | 48/57 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Products per pallet | 128 pc(s) |
| Products per pallet layer | 16 pc(s) |
| Products per pallet (UK) | 192 pc(s) |
| Products per pallet layer (UK) | 24 pc(s) |
Technical details
| Specification | Value |
|---|---|
| Font styles | ANK |
| Box contents | Main unit, Mount plate, Paper spacer, Power switch cover, Roll paper |
| Lifetime | 17000000 lines |
Other features
| Specification | Value |
|---|---|
| Buffer size | 12 KB |
| Mean cycles between failures (MCBF) | 65000000 |
| Print head life | 150.000.000 Impulse |
