T1721MSC-B1-STD POS monitor
43.2 cm (17") 1280 x 1024 pixels SXGA LED Touchscreen
Model T1721MSC-B1-STD
34 specifications
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- Power20 W
- Weight4.4 kg
- ColourBlack
- Power source typeAC, DC
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Power
- 20 W
- Weight
- 4.4 kg
- Colour
- Black
- Power source type
- AC, DC
- Brand
- iiyama
- Category
- POS Monitor
- Model
- T1721MSC-B1-STD
- Part number
- T1721MSC-B1-STD
- Also known as
- iiyama T1721MSC-B1-STD POS monitor 43.2 cm (17") 1280 x 1024 pixels SXGA LED Touchscreen
Specifications
34 specifications in 6 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| HD type | SXGA |
| Display type | LED |
| Display brightness | 215 cd/m² |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| Contrast ratio (typical) | 1000:1 |
| Effective viewing area | 338 x 270.5 mm |
| Native aspect ratio | 5:4 |
| Panel type | TN |
| Pixel pitch | 0.264 x 0.264 mm |
| Response time | 5 ms |
| Surface hardness | 7H |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC, DC |
| Power | 20 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 198 mm |
| Height | 364 mm |
| Weight | 4.4 kg |
| Width | 392.5 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, CB, TÜV type, CU, cULus |
