WORKSTATION 7550 vPro

Model WORKSTATION 7550 vProPart no. 1000965EAN 4039407044504

104 specifications

Overview

Brand: TERRA
Category: PCs/Workstations
Model: WORKSTATION 7550 vPro
Part number: 1000965
EAN / UPC: 4039407044504
Also known as: TERRA WORKSTATION 7550 vPro Intel® Xeon® W-2123 16 GB DDR4-SDRAM 750 GB HDD+SSD NVIDIA® Quadro® P2000 Windows 10 Pro for Workstations Midi Tower Black

104 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon®
Processor model	W-2123
Processor cores	4
Processor threads	8
Processor boost frequency	3.9 GHz
Processor frequency	3.6 GHz
Processor cache	8.25 MB
Bus type	QPI
System bus rate	0 GT/s
Processor lithography	14 nm
Processor codename	Skylake
Thermal Design Power (TDP)	120 W
Tcase	65 °C
Maximum number of PCI Express lanes	48
PCI Express configurations	1x16, 1x4, 1x8
PCI Express slots version	3.0
Number of processors installed	1
Processor socket	LGA 2066 (Socket R4)
Stepping	U0
Maximum internal memory supported by processor	512 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600,1866,2133,2400,2666 MHz
Memory bandwidth supported by processor (max)	85.3 GB/s
ECC supported by processor	Yes

Specification	Value
Total storage capacity	750 GB
Optical drive type	DVD±RW
Storage media	HDD+SSD
Number of storage drives installed	2
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA III
Number of SSDs installed	1
SSD capacity	250 GB
SSD interface	SATA III

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	NVIDIA® Quadro® P2000

Specification	Value
Product type	Workstation

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Ethernet LAN (RJ-45) ports	2
Line-out	Yes
Line-in	Yes
PS/2 ports quantity	2

Specification	Value
PCI Express x8 (Gen 3.x) slots	2
PCI Express x16 (Gen 3.x) slots	2

Specification	Value
Power supply	650 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Specification	Value
Chassis type	Midi Tower
Product colour	Black

Specification	Value
Operating system installed	Windows 10 Pro for Workstations

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	No
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
Processor ARK ID	125036
Processor code	SR3LJ
Processor package size	45 x 52.5 mm
Scalability	1S
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Conflict-Free processor	Yes
