Server 4030 G3 WS2016S (SSD)
Model Server 4030 G3 WS2016S (SSD)Part no. 1100976
59 specifications
- ProcessorIntel® Xeon® E3 v6
- Memory16 GB
- Storage960 GB
- GraphicsNot available
- TypePC
- OSWindows Server 2016 Standard
Overview
- Processor
- Intel® Xeon® E3 v6
- Memory
- 16 GB
- Storage
- 960 GB
- Graphics
- Not available
- Type
- PC
- OS
- Windows Server 2016 Standard
- Brand
- TERRA
- Category
- PCs/Workstations
- Model
- Server 4030 G3 WS2016S (SSD)
- Part number
- 1100976
- Also known as
- TERRA Server 4030 G3 WS2016S (SSD) Intel® Xeon® E3 v6 E3-1245V6 16 GB DDR4-SDRAM 960 GB Windows Server 2016 Standard Tower PC Black
Specifications
59 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E3 v6 |
| Processor model | E3-1245V6 |
| Processor cores | 4 |
| Processor frequency | 3.7 GHz |
| Number of processors installed | 1 |
| Processor socket | LGA 1151 (Socket H4) |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2133 MHz |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 960 GB |
| Optical drive type | DVD±RW |
| Storage media | SSD |
| Number of storage drives installed | 2 |
| Number of SSDs installed | 2 |
| SSD capacity | 480 GB |
| SSD interface | SATA III |
| Card reader integrated | No |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card model | Intel® HD Graphics P630 |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | Intel® C236 |
Optical drive
| Specification | Value |
|---|---|
| Optical drives quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 4 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x8 (Gen 3.x) slots | 2 |
Power
| Specification | Value |
|---|---|
| Power supply | 650 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Placement supported | Vertical |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Server 2016 Standard |
Display
| Specification | Value |
|---|---|
| Display included | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 75% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 570 mm |
| Height | 440 mm |
| Weight | 26 kg |
