8550 BTO
Model 8550 BTOPart no. 1000982EAN 4039407064656
82 specifications
- ProcessorAMD Ryzen Threadripper PRO
- Memory32 GB
- Storage500 GB
- GraphicsNVIDIA RTX A4000
- TypeWorkstation
- OSWindows 10 Pro
Overview
- Processor
- AMD Ryzen Threadripper PRO
- Memory
- 32 GB
- Storage
- 500 GB
- Graphics
- NVIDIA RTX A4000
- Type
- Workstation
- OS
- Windows 10 Pro
- Brand
- TERRA
- Category
- PCs/Workstations
- Model
- 8550 BTO
- Part number
- 1000982
- EAN / UPC
- 4039407064656
- Also known as
- TERRA 8550 BTO AMD Ryzen Threadripper PRO 5965WX 32 GB DDR4-SDRAM 500 GB SSD NVIDIA RTX A4000 Windows 10 Pro Tower Workstation Black
Specifications
82 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen Threadripper PRO |
| Processor generation | AMD Ryzen Threadripper PRO 5000 WX-Series |
| Processor model | 5965WX |
| Processor cores | 24 |
| Processor threads | 48 |
| Processor boost frequency | 4.5 GHz |
| Processor frequency | 3.8 GHz |
| Performance-core base frequency | 3.8 GHz |
| Processor cache | 128 MB |
| Processor cache type | L3 |
| Number of processors installed | 1 |
| Processor base power | 280 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Maximum internal memory | 2 TB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 8x DIMM |
| Buffered memory type | Registered (buffered) |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Optical drive type | DVD±RW |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 500 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 500 GB |
| SSD interface | M.2, PCI Express 4.0 |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA RTX A4000 |
| Discrete graphics card memory | 16 GB |
| Discrete graphics memory type | GDDR5 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Graphics card DisplayPorts quantity | 4 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Market positioning | High performance |
| Motherboard chipset | AMD WRX80 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Intel® X550-AT2 |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 8 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| S/PDIF out port | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 4 |
| PCI Express x16 (Gen 4.x) slots | 7 |
Power
| Specification | Value |
|---|---|
| Power supply | 2000 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Power consumption (typical) | 50 W |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Number of 5.25" bays | 1 |
| Number of 2.5" bays | 5 |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
Display
| Specification | Value |
|---|---|
| Display included | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 75% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 617 mm |
| Height | 598 mm |
| Weight | 21.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse connectivity | Wired |
| Mouse included | Yes |
| Mouse included on selected markets only | Yes |
| Keyboard included | Yes |
| Keyboard included on selected markets only | Yes |
| Input device model | TERRA Wheel Mouse Optical |
