7600 BTO
Model 7600 BTOPart no. 1000979EAN 4039407056828
76 specifications
- ProcessorAMD Ryzen™ 7
- Memory16 GB
- Storage500 GB
- GraphicsNVIDIA RTX A2000
- TypeWorkstation
- OSWindows 10 Pro
Overview
- Processor
- AMD Ryzen™ 7
- Memory
- 16 GB
- Storage
- 500 GB
- Graphics
- NVIDIA RTX A2000
- Type
- Workstation
- OS
- Windows 10 Pro
- Brand
- TERRA
- Category
- PCs/Workstations
- Model
- 7600 BTO
- Part number
- 1000979
- EAN / UPC
- 4039407056828
- Also known as
- TERRA 7600 BTO AMD Ryzen™ 7 5800X 16 GB DDR4-SDRAM 500 GB SSD NVIDIA RTX A2000 Windows 10 Pro Tower Workstation Black
Specifications
76 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ 7 |
| Processor generation | AMD Ryzen 5000 Series |
| Processor model | 5800X |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.7 GHz |
| Processor frequency | 3.8 GHz |
| Performance-core base frequency | 3.8 GHz |
| Processor cache | 36 MB |
| Processor cache type | L2 & L3 |
| Number of processors installed | 1 |
| Processor base power | 105 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 4x DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Optical drive type | DVD±RW |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 500 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 500 GB |
| SSD interface | M.2, PCI Express 4.0 |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA RTX A2000 |
| Discrete graphics card memory | 6 GB |
| Number of discrete graphics cards | 1 |
| Maximum on-board graphics card memory | 5 GB |
| Graphics card Mini DisplayPort ports quantity | 4 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Market positioning | Everyday |
| Motherboard chipset | AMD X570 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Intel® I211-AT |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPorts quantity | 5 |
| DisplayPort version | 1.4 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| S/PDIF out port | Yes |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 3 |
Power
| Specification | Value |
|---|---|
| Power supply | 650 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Power consumption (typical) | 50 W |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
Display
| Specification | Value |
|---|---|
| Display included | No |
Audio
| Specification | Value |
|---|---|
| Audio system | High Definition Audio |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 75% |
Packaging content
| Specification | Value |
|---|---|
| Mouse connectivity | Wired |
| Mouse included | Yes |
| Mouse included on selected markets only | Yes |
| Keyboard included | Yes |
| Keyboard included on selected markets only | Yes |
| Input device model | TERRA Wheel Mouse optical |
Keyboard
| Specification | Value |
|---|---|
| Keyboard connectivity | Wired |
