TERRA 1001136 PC Intel Atom® 230

1 GB DDR2-SDRAM 160 GB 950 Windows XP Home Edition Micro Tower Black, Silver

Model 1001136EAN 4039407013838

110 specifications

ProcessorIntel Atom®
Memory1 GB
Storage160 GB
Graphics950
TypePC
OSWindows XP Home Edition

See all specifications

Overview

Processor: Intel Atom®
Memory: 1 GB
Storage: 160 GB
Graphics: 950
Type: PC
OS: Windows XP Home Edition

Brand: TERRA
Category: PCs/Workstations
Model: 1001136
Part number: 1001136
EAN / UPC: 4039407013838
Also known as: TERRA 1001136 PC Intel Atom® 230 1 GB DDR2-SDRAM 160 GB 950 Windows XP Home Edition Micro Tower Black, Silver

Specifications

110 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	230
Processor cores	1
Processor threads	2
Processor frequency	1.6 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor front side bus	533 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Atom 200 Series
Processor codename	Diamondville
Thermal Design Power (TDP)	4 W
Tcase	85.2 °C
Processor socket	BGA 437
Number of Processing Die Transistors	47 M
Processing Die size	26 mm²
CPU multiplier (bus/core ratio)	12
Stepping	C0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Maximum internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 1 GB
Memory clock speed	800 MHz

Storage

Specification	Value
Total storage capacity	160 GB
Optical drive type	DVD-RW
HDD interface	SATA II
HDD speed	7200 RPM
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	950
Graphics card RAMDAC	400 MHz
Maximum graphics card memory	0.224 GB
Graphics card family	Intel

Performance

Specification	Value
Product type	PC
Audio output channels	5.1 channels

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Wi-Fi	No
Networking features	Fast Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	2
DC-in jack	Yes

Expansion slots

Specification	Value
PCI slots	1
Expansion slots	2 x Serial-ATA II

Power

Specification	Value
Power supply type	Fortron-Source FSP350
Power requirements	230 V, 4 A, 50 Hz
Power supply	350 W

Design

Specification	Value
Chassis type	Micro Tower
Product colour	Black, Silver
External drive bays	2 x 5.25", 1 x 3.5"
Internal drive bays	1 x 3.5"

Software

Specification	Value
Operating system installed	Windows XP Home Edition
Drivers included	Yes
Trial software	Kaspersky Internet Security
Bundled software	Microsoft Works SE 9.0 Adobe Reader

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	35635
Processor code	SLB6Z
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Weight & dimensions

Specification	Value
Width	180 mm
Depth	400 mm
Height	360 mm

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Remote control included	No

Certificates

Specification	Value
Certification	EnergyStar, ISO 9001, CE

Other features

Specification	Value
TV tuner integrated	No
Motherboard	Foxconn 45CTP
