Shuttle XS36V-703L PC Intel Atom® D2550

2 GB DDR3-SDRAM 320 GB HDD Mini PC Black

Model XS36V-703LEAN 4046047102617

129 specifications

ProcessorIntel Atom®
Memory2 GB
Storage320 GB
GraphicsNot available
SpeedWi-Fi 4 (802.11n)
TypeMini PC

See all specifications

Overview

Processor: Intel Atom®
Memory: 2 GB
Storage: 320 GB
Graphics: Not available
Speed: Wi-Fi 4 (802.11n)
Type: Mini PC

Brand: Shuttle
Category: PCs/Workstations
Model: XS36V-703L
Part number: XS36V-703L
EAN / UPC: 4046047102617
Also known as: Shuttle XS36V-703L PC Intel Atom® D2550 2 GB DDR3-SDRAM 320 GB HDD Mini PC Black

Specifications

129 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D2550
Processor cores	2
Processor threads	4
Processor frequency	1.86 GHz
Processor cache	1 MB
Processor cache type	L2
Bus type	DMI
FSB Parity	No
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Atom D2500 Series
Processor codename	Cedarview
Thermal Design Power (TDP)	10 W
Tjunction	100 C
Maximum number of PCI Express lanes	4
Number of processors installed	1
Processor socket	BGA 559
Stepping	B3
Maximum internal memory supported by processor	4 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800,1066 MHz
Memory bandwidth supported by processor (max)	6.4 GB/s
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Maximum internal memory	4 GB
Internal memory type	DDR3-SDRAM
Memory slots	2
Memory channels	Single-channel

Storage

Specification	Value
Total storage capacity	320 GB
Optical drive type	No
Storage media	HDD
Number of HDDs installed	1
HDD capacity	320 GB
HDD interface	SATA
HDD size	2.5"
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Integrated
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	640 MHz

Performance

Specification	Value
Product type	Mini PC
Motherboard chipset	Intel NM10

Optical drive

Specification	Value
Optical drives quantity	0

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Thunderbolt ports quantity	1
HDMI ports quantity	1
HDMI version	1.3
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	No
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
PS/2 ports quantity	0
S/PDIF out port	No
DC-in jack	Yes
SmartCard slot	No
Serial ports quantity	2

Power

Specification	Value
Power supply	40 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Placement supported	Vertical
Product colour	Black
Cooling type	Passive
Form factor	1,3L-sized PC

Software

Specification	Value
Operating system installed	No

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	36 bit
Physical Address Extension (PAE)	Yes
Processor ARK ID	65470
Processor code	SR0VY
Processor package size	22 X 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	36 mm
Depth	200 mm
Height	160 mm
Weight	1.6 kg

Packaging content

Specification	Value
Mouse included	No
Keyboard included	No
Cables included	AC
AC adapter included	Yes
Manual	Yes

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	CE, FCC, BSMI, C-Tick, CCC, CB, BSMI, ETL, Eup Lot6
