XPC G5 8300HA
Model XPC G5 8300HAPart no. G5 8300HA
93 specifications
- ProcessorIntel® Pentium® 4
- Memory1 GB
- Storage200 GB
- GraphicsAMD Radeon X1300 Pro
- TypePC
- OSWindows XP Home Edition
Overview
- Processor
- Intel® Pentium® 4
- Memory
- 1 GB
- Storage
- 200 GB
- Graphics
- AMD Radeon X1300 Pro
- Type
- PC
- OS
- Windows XP Home Edition
- Brand
- Shuttle
- Category
- PCs/Workstations
- Model
- XPC G5 8300HA
- Part number
- G5 8300HA
- Also known as
- Shuttle XPC G5 8300HA Intel® Pentium® 4 524 1 GB DDR-SDRAM 200 GB AMD Radeon X1300 Pro Windows XP Home Edition Desktop PC
Specifications
93 specifications in 17 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Pentium® 4 |
| Processor model | 524 |
| Processor cores | 1 |
| Processor threads | 2 |
| Processor frequency | 3.06 GHz |
| Processor cache | 1 MB |
| Processor cache type | L2 |
| Processor front side bus | 533 MHz |
| Bus type | FSB |
| FSB Parity | No |
| Processor lithography | 90 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Pentium 4 500 Series supporting Hyper-Threading Technology |
| Processor codename | Prescott |
| Thermal Design Power (TDP) | 84 W |
| Tcase | 67.7 °C |
| Processor socket | LGA 775 (Socket T) |
| Number of Processing Die Transistors | 125 M |
| Processing Die size | 112 mm² |
| CPU multiplier (bus/core ratio) | 23 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Internal memory type | DDR-SDRAM |
| Memory layout (slots x size) | 2 x 0.5 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 200 GB |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | AMD Radeon X1300 Pro |
| Maximum graphics card memory | 0.256 GB |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | Intel® 915G Express |
Optical drive
| Specification | Value |
|---|---|
| DVD write speed | 16x |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet Marvell 88E8001 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 2 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Yes |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| S/PDIF out port | Yes |
| TV-out | Yes |
| TV-out type | S-Video |
| Serial ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 x 32 Bit PCI (v2.2). |
Power
| Specification | Value |
|---|---|
| Power supply type | SilentX 250 W |
| Power supply | 250 W |
| Power supply input voltage | 100/240 V |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows XP Home Edition |
| Mac compatibility | No |
| Bundled software | Ahead Nero, CyberLink PowerDVD. |
Display
| Specification | Value |
|---|---|
| Display included | Yes |
| Display | VFD Media-Display |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 27462 |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 310 mm |
| Height | 185 mm |
Certificates
| Specification | Value |
|---|---|
| Safety | UL, TÜV, CB |
| Certification | FCC, CE, BSMI. |
