NEC 100014901 PC/workstation Intel Atom® x5-Z8350

4 GB DDR3L-SDRAM 64 GB Flash Windows 10 IoT Enterprise Mini PC Black

Model 100014901EAN 4719622291432

95 specifications

ProcessorIntel Atom®
Memory4 GB
Storage64 GB
GraphicsNot available
SpeedWi-Fi 5 (802.11ac)
TypeMini PC

See all specifications

Overview

Processor: Intel Atom®
Memory: 4 GB
Storage: 64 GB
Graphics: Not available
Speed: Wi-Fi 5 (802.11ac)
Type: Mini PC

Brand: NEC
Category: PCs/Workstations
Model: 100014901
Part number: 100014901
EAN / UPC: 4719622291432, 4719622294785
Also known as: NEC 100014901 PC/workstation Intel Atom® x5-Z8350 4 GB DDR3L-SDRAM 64 GB Flash Windows 10 IoT Enterprise Mini PC Black

Specifications

95 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	x5-Z8350
Processor cores	4
Processor threads	4
Processor boost frequency	1.92 GHz
Processor frequency	1.44 GHz
Processor cache	2 MB
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Atom x5 Series
Processor codename	Cherry Trail
Scenario Design Power (SDP)	2 W
Tjunction	90 °C
Maximum number of PCI Express lanes	1
PCI Express configurations	1x1
PCI Express slots version	2.0
Processor socket	BGA 592
Maximum internal memory supported by processor	2 GB
Memory types supported by processor	DDR3L-RS-SDRAM
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	12.8 GB/s

Memory

Specification	Value
Internal memory	4 GB
Maximum internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Memory slots	1x SO-DIMM
Memory clock speed	1600 MHz
Memory channels	Single-channel

Storage

Specification	Value
Total storage capacity	64 GB
Optical drive type	No
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 400
Maximum on-board graphics card memory	2 GB
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	500 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Number of execution units	12

Performance

Specification	Value
Product type	Mini PC

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth	Yes
Bluetooth version	4.2
Wake-on-LAN ready	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
DVI port	No
RS‐232/422 port	Yes

Design

Specification	Value
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 10 IoT Enterprise

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Intel 64	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Processor ARK ID	93361
Processor code	SR2KT
Processor package size	17 x 17 mm
Intel® Turbo Boost Technology	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Conflict-Free processor	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90%

Weight & dimensions

Specification	Value
Width	93 mm
Depth	97 mm
Height	32 mm
Weight	700 g

Packaging data

Specification	Value
Package width	248 mm
Package depth	212 mm
Package height	59 mm
Package weight	1 kg

Packaging content

Specification	Value
Manual	Yes

Certificates

Specification	Value
Certification	CE, FCC class B
